Running GUI Applications inside Docker Containers

Saravanan Sundaramoorthy
3 min readFeb 5, 2018

--

While the IT world is embracing Containers Technology primarily for Enterprise Server Applications, There is also a huge scope of Docker Containers impacting the Desktop and Development Environment. We leverage this heavily at Admatic, where we containerise every application and service we use — further including the GUI applications and tools that we use for Day to day Development — what took us days is now just a second away. :)

If we want to switch to Deep Learning Dev environment — its 1 Click, If we want Android Dev Env — its just another 1 sec away, Need to integrate Computer vision Algorithms with JNI wrappers for Android NDK Integration with TensorFlow Models — Boom!, just a sec away.

I repeat, what took us few days is now just a second away :)

Want to setup a similar Wow Dev environment at your Office, Get in touch!

Thanks to Docker Containers that is revolutionising the current DevOps landscape and we plan to revolutionise the current development environment landscape with the same.

Here will share you how to Containerise a GUI app in Docker

There can be two types of applications (usually services) that you can containerise,

  • Applications that run as a Background Service (like a Database, WebServer, etc)
  • GUI Applications that (obviously!) run in the foreground

The second option is what we will see now,

For a GUI Application to run, we need to have a XServer which is available as part of every Linux Desktop Environment, But within a Container we don’t have any XServer — so we will

  • share the Host’s XServer with the Container by creating a volume
  • --volume="$HOME/.Xauthority:/root/.Xauthority:rw"
  • share the Host’s DISPLAY environment variable to the Container
  • --env="DISPLAY"
  • run container with host network driver with
  • --net=host

Use this Dockerfile to build an image with a sample GUI application for testing,

$ cat Dockerfile

FROM centos
RUN yum install -y xeyes
CMD ["/usr/bin/xeyes"]

$ sudo docker build -t gui-app .

$ sudo docker run --net=host --env="DISPLAY" --volume="$HOME/.Xauthority:/root/.Xauthority:rw" gui-app

You should see the xeyes GUI application now displayed on your Host OS Desktop.

Now lets build Android Studio Docker Image with,

$ sudo docker build -t android-studio .

$ cat Dockerfile

FROM ubuntu:14.04
MAINTAINER Admatic Engineering Team@ADMATIC.IN
ENV DEBIAN_FRONTEND=noninteractiveRUN apt-get update# Default jdk
RUN apt-get install -y default-jdk
# 32-bit dependencies of android and utils
RUN apt-get install -y \
bison \
git \
gperf \
lib32gcc1 \
lib32bz2-1.0 \
lib32ncurses5 \
lib32stdc++6 \
lib32z1 \
libc6-i386 \
libxml2-utils \
make \
zip
# Download and unzip Android Studio for Linux
ADD http://dl.google.com/dl/android/studio/ide-zips/1.2.1.1/android-studio-ide-141.1903250-linux.zip /opt/android-studio.zip
RUN cd /opt/ && unzip android-studio.zip && rm android-studio.zip
CMD /opt/android-studio/bin/studio.sh

This will start Android Studio running from inside Container.

$ sudo docker run --net=host --env="DISPLAY" --volume="$HOME/.Xauthority:/root/.Xauthority:rw" android-studio

There are much more interesting things we can do on top of this, Currently this will need Linux Host to run, How about getting this GUI app running on a Windows OS? Mac OS?

We will see that in another post.
