Trend, Seasonality, Moving Average, Auto Regressive Model : My Journey to Time Series Data with Interactive Code

GIF from this website

So recently I have been working with Time Series Data. And I wanted to review what a Time series is as well as make my understanding more concert on Time Series Data.

Please note this post is for my future self and for me to gain more deeper understanding of Time Series.

Definition

Image from this website

There are multiple of different sources defining the term ‘Time Series’ , so here I’ll try to give a general definition that is easy for my self to understand.

Image from this website
A time series is a series of data points indexed (or listed or graphed) in time order.

As seen above, wiki gives very straight forward definition, any data in a sequential time order. Now lets take a look at the definition from investopedia.

Image from this website
A time series is a sequence of numerical data points in successive order.

As seen above, we can get a general idea of what a time series data can be. It can be any data recored over time in sequential order. From the start we can think of stock prices, however videos, languages, songs, and MRI Scans can be thought of Time Series data as well.


Types of Time Series Data

Image from this website

Above is an example image of Stock Prices, and we can observe that in the x-axis we have the time index, and in the y-axis we have the stock prices of different markets.

Gif from this website and this website

Another great example of Time Series data in computer vision world would be video (above is a GIF), since we capture frame by frame in one time sequence. And we can clearly see MRI scan can be named as Time Series Data.


Goals of Time Series

Image from this website

One obvious example use case of Time Series is predicting stock prices. (Well if this was so easy, a lot of Data Scientist would be rich.) But I wanted to add some different uses cases, we can even use GAN’s to predict the next frame of a given video, or MRI Scan. Imagine where a GAN takes in few sequences of your MRI Scan and generates a MRI scan if you had cancer inside your body. (That would be pretty cool.). So in general we want to forecast / predict the next value when it comes to Time Series.


Trend / Seasonality / Noise

Image from this website

Before we move on we need to discuss something important, most time series data can be described by three components. And those are trend, seasonality and bias.

Trend → a general systematic linear or (most often) nonlinear component that changes over time and does not repeat
Seasonality → a general systematic linear or (most often) nonlinear component that changes over time and does repeat
Noise → a non-systematic component that is nor Trend/Seasonality within the data

Right Image → Python Code to Create the Visualization
Red Line → Apple Stock Prices from 1985
Blue Line → Trend for Apple Stock Price
Green Line → Residual (Noise) for Apple Stock Price
Orange Line → Seasonal (Yearly) trend for Apple Stock Price

With simple code and statsmodel library we can easily see how each components related to one another. We can observe that there is a seasonal increase every year, as well as general trend for apple stock price is increasing.


Approach to Predict / Forecast

Left/Right Image → Standard Window Avg / Exponentially Moving Avg

There are lot of different methods that we can use when we want perform forecasting. I will mention the methods that I have found during my research.

Standard / Exponentially Moving Average → calculation to analyze data points by creating series of averages of different subsets of the full data set

Auto Regression → is a representation of a type of random process; as such, it is used to describe certain time-varying processes in nature, economics, etc

Linear/Polynomial Regressionregression analysis in which the relationship between the independent variable x and the dependent variable y is modelled as an nth degree polynomial (or 1 degree for linear)

ARMA → model that provide a parsimonious description of a (weakly) stationary stochastic process in terms of two polynomials, one for the autoregression and the second for the moving average.

ARIMA (Autoregressive integrated moving average) → is a generalization of an autoregressive moving average (ARMA) model. Both of these models are fitted to time series data either to better understand the data or to predict future points in the series (forecasting)

Seasonal ARIMA → seasonal AR and MA terms predict xt using data values and errors at times with lags that are multiples of S (the span of the seasonality)

ARIMAX → An ARIMA model with covariate on the right hand side

Recurrent Neural Network (LSTM) → a class of artificial neural network where connections between nodes form a directed graph along a sequence in which allows it to exhibit dynamic temporal behavior for a time sequence.

As seen above even a simple Auto Regressive can fit the stock price quite perfectly. Please click here to read about the difference between ARMA, ARIMA and ARIMAX.


Interactive Code

For Google Colab, you would need a google account to view the codes, also you can’t run read only scripts in Google Colab so make a copy on your play ground. Finally, I will never ask for permission to access your files on Google Drive, just FYI. Happy Coding!

To access the code used for this post, please click here.


Final Words

I hope to continue my research to gain a deeper understanding about Time Series. Since I think its very common problem in every industry.
