Look ma no server!

Going serverless on Openshift with OpenWhisk

Set of ‘look ma no server’ demos to enjoy OpenWhisk

A while ago I was proposed to run a tech lab around the ‘serverless’ buzzword. By then I was already aware of the concept (I tried AWS Lambda back in 2015) and actually liked it, but to be honest since those experiments I had had very little contact with serverless tech, until Red Hat released some interesting labs (more on this later) and I started again to feel the rush of pushing code and run it live. So… if you haven’t tried it, you should!

TL;DR

I’ll introduce you to a set of explained simple demos of increasing complexity.
I also give some hints to make sense of ‘serverless’ and ‘function as a service’ in the real world.
This is part 1 of (maybe) 3, other parts (code is already included in folder ./node) will include an Alexa Skill and an integration with AHOI API

Pre-requisites

In order to run these demos you need either an accessible [Openshift](https://www.openshift.com/learn/what-is-openshift/) environment with around 5GB RAM / 50GB disk / 3 vCPU or a computer at hand with minishift installed and those free resources.

$ minishift version
minishift v1.26.1+1e20f27

Go here for instructions to install minishift.

You’ll also need the Openshift CLI, go here for instructions to install it.

Where’s the code?

In order to follow the guide my suggestion is to clone, fork, download the code. The repo is here.

$ git clone https://github.com/cvicens/openwhisk-demo
$ cd openwhisk-demo

By default I’ll assume you’re in folder `openwhisk-demo` unless otherwise advised.

Setting up the minishift environment

If you already have an Openshift environment you can skip this. You could also skip this if you want to use the learning area here (maybe you need to make slight changes… honestly I haven’t tried but it should work well)

In order to set up our demo, we need to run ./01-setup-minishift.sh. Please have a look to ./00-environment.sh to confirm the default values for the minishift profile we’re going to create.

Pay special attention to variables MINISHIFT_VM_DRIVER and PLATFORM to make then match your environment!
$ ./01-setup-minishift.sh

After a while should get messages like these…

$ ./01-setup-minishift.sh
Profile ‘openwhisk’ set as active profile.
No Minishift instance exists. New ‘memory’ setting will be applied on next ‘minishift start’
No Minishift instance exists. New ‘cpus’ setting will be applied on next ‘minishift start’
No Minishift instance exists. New ‘vm-driver’ setting will be applied on next ‘minishift start’
No Minishift instance exists. New ‘disk-size’ setting will be applied on next ‘minishift start’
Add-on ‘admin-user’ enabled
Add-on ‘anyuid’ enabled
— Starting profile ‘openwhisk’
— Check if deprecated options are used … OK
— Checking if https://github.com is reachable … OK
— Checking if requested OpenShift version ‘v3.11.0’ is valid … OK

Now please log in to your minishift with the next script.

$ ./02-login-minishift.sh

Deploying OpenWhisk on Openshift

If you have your own OpenShift environment, don’t forget to login in using the oc tool… otherwise you’ll get this message: You need to log in your Openshift cluster first…

Deploying OpenWhisk on OpenShift means basically applying a template, a one-liner like this.

oc process -f https://git.io/openwhisk-template | oc create -f -

To make it a little easier (I hope) I’ve prepared a script that creates a project/namespace (by default openwhisk-demo), deploys OpenWhisk in it, and downloads and sets up the OpenWhisk CLI wsk in ./bin

So let’s do this, please run the script as follows.

Please ignore this error if hit: unable to recognize no matches for kind “CronJob” in version “batch/v2alpha1”
You can also use a local version of the template I fixed, to do so, look for ‘# Deploying OpenWhisk, choose the remote (default) or local template’
$ ./03-deploy-opewhisk.sh
Now using project “openwhisk-demo” on server “https://master.serverless-e442.openshiftworkshop.com:443".

to build a new example application in Ruby.
configmap/whisk.config created

alarmprovider-7755754445-hp2hc 0/1 Init:0/2 0 3s
controller-0 0/1 Init:0/2 0 5s
couchdb-0 0/1 ContainerCreating 0 4s
install-catalog-5jfjv 0/1 Init:0/1 0 5s
invoker-0 0/1 Init:0/2 0 4s
nginx-85697b95cf-zkgzl 0/1 Init:0/1 0 3s

Finally you should see something like this, it’s a list of items you get by invoking wsk list. It means everything is set up correctly.

Beware that commands are run like this ./bin/wsk -i because wsk is not in your PATH, -i is needed because we assume you don’t have an OpenShift environment using certificates signed by a recognized CA.
 ./bin/wsk -i list
Entities in namespace: default
packages
/whisk.system/combinators shared

actions
/whisk.system/samples/curl private nodejs:6

triggers
rules

Running the demos

There are several Javascript and Java examples, in general demos are divided into two scripts:

  • one to deploy the function
  • and another one to run it

Let’s start with the basics.

NodeJS greeter.js demo

The idea is to deploy a function like this one below, file ./node/greeter.js.

function main(params) {
var name = params.name || ‘Guest’;
var place = params.place || ‘OpenShift Cloud Functions’;
return {payload: ‘Welcome to ‘ + place + ‘, ‘ + name};
}

To deploy the function you only need to to this.

Pay attention to the--web flag, this means we can invoke this action using HTTP
$ ./bin/wsk -i action update — web=true greeter ./node/greeter.js
ok: updated action greeter
The provided script 04-node-action-deploy.sh makes sure wsk is set up properly but it’s not mandatory to use it

There are several way to run our function, using wsk synchronously/asynchronously, HTTP GET/POST, …

Calling our function synchronously, --result instructs to wait for the result.

$ ./bin/wsk -i action invoke — result greeter -p name ‘Carlos’ -p place ‘Lisbon’
{
“payload”: “Welcome to Lisbon, Carlos”
}

Same call, but this time in an asynchronous way

$ ./bin/wsk -i action invoke greeter -p name ‘Carlos’ -p place ‘Lisbon’
ok: invoked /_/greeter with id 6c64b7206b5e483fa4b7206b5e483fad

Now to get the result we do as follows.

$ ./bin/wsk -i activation result 6c64b7206b5e483fa4b7206b5e483fad
{
“payload”: “Welcome to Lisbon, Carlos”
}

If we want to use HTTP, first we need the URL.

$ ./bin/wsk -i action get greeter — url | awk ‘FNR==2{print $1}’
https://openwhisk-openwhisk-demo.apps.example.com/api/v1/web/whisk.system/default/greeter

If we store the result in a variable, we can then use `curl` for testing.

> **Pay attention!** You need to add ‘.json’ to the URL for the action to return JSON. ‘.text’ would return text, etc. Go [here](https://medium.com/openwhisk/serverless-http-handlers-with-openwhisk-90a986cc7cdd) for nice article mentioning web actions and other content types.
$ export WEB_URL=`./bin/wsk -i action get greeter — url | awk ‘FNR==2{print $1}’`
$ curl -k — silent -X GET ${WEB_URL}.json?name=Carlos\&place=Madrid
{
“payload”: “Welcome to Madrid, Carlos”
}
$ curl -k — silent -d ‘{“name”:”Carlos”, “place”:”Barcelona”}’ -H “Content-Type: application/json” -X POST $WEB_URL.json
{
“payload”: “Welcome to Barcelona, Carlos”
}

You can run all these calls with 05-node-action-run.sh

Java simple demo

The OpenWhisk Java runtime needs your function to have this exact signature.

public static com.google.gson.JsonObject main(com.google.gson.JsonObject);

Although it’s not necessary, as we just said the only requirement is to have a Java class including a method as specified, in this example we’re going to use a Maven archetype.

Our first task is to install the archetype

This can also be done by running the script ./06-maven-install-archetype.sh

$ git clone https://github.com/apache/incubator-openwhisk-devtools ./tmp/incubator-openwhisk-devtools
$ cd ./tmp/incubator-openwhisk-devtools/java-action-archetype
$ mvn -DskipTests=true -Dmaven.javadoc.skip=true -B -V clean install

Let’s create and deploy a Java function using the archetype as follows

You can use the script 07-maven-action-deploy.sh to do this task or you can also adapt it to your needs, java package name, artifact ID, etc.
$ export ARTIFACT_ID=”demo-function”
$ mvn archetype:generate \
-DinteractiveMode=false \
-DarchetypeGroupId=org.apache.openwhisk.java \
-DarchetypeArtifactId=java-action-archetype \
-DarchetypeVersion=1.0-SNAPSHOT \
-DgroupId=com.redhat.serverless \
-DartifactId=${ARTIFACT_ID}

$ cd ${ARTIFACT_ID}
$ mvn clean package

After generating and packaging the sample function a jar file should have been generated at ./${ARTIFACT_ID}/target/${ARTIFACT_ID}.jar

Next step is to deploy our function in OpenWhisk, to do so we need the name of the action (in the next example is `demo`) the path to the jar file and the fully qualified name of the class that contains our function.

By default when using the archetype -DgroupId=com.redhat.serverless means --main com.redhat.serverless.FunctionApp
./bin/wsk -i action update demo ./${ARTIFACT_ID}/target/${ARTIFACT_ID}.jar — main com.redhat.serverless.FunctionApp

Running the action

Running the action is as easy as before.

Again you can use this script 08-maven-action-run.sh
./bin/wsk -i action invoke demo — result

Java QR generator demo

I’ve taken the code by Philippe Suter and used it in a Java class generated using the archetype I introduced before.

The code of the QR generator class is original from Philippe Suter, and can be found here.

The mechanics are the same as before, the only change is the code of the function itself.

To deploy the function run the deploy script.

$ ./09-maven-action-qr-gen-deploy.sh

— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
[INFO] BUILD SUCCESS
[INFO] — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
[INFO] Total time: 3.288 s
[INFO] Finished at: 2018–12–11T19:09:11+01:00
[INFO] Final Memory: 22M/210M
[INFO] — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
ok: whisk auth set. Run ‘wsk property get — auth’ to see the new value.
ok: whisk API host set to openwhisk-openwhisk-demo.apps.example.com
ok: updated action qr

To run the action you can either call the action like this…

By adding | jq -r ‘.qr’ | base64 — decode > qr.png you can decode the base64 into a proper PNG
$ ./bin/wsk -i action invoke -br qr -p text ‘Hola mundo!’
{
“qr”: “iVBORw0KGgoAAAANSUhEUgAAASwAAAEsAQAAAABRBrPYAAABGklEQVR42u3aOxLCIBCAYag8BkdNjsoRLK1A3hBNokWA0fkpHBI+q51lYSfCfjPuAgaDwWCwn2IPkYaKM2nX9ELCxrH4ZFflZumnXYANYmsIkWr+EGIHm8J8ntxgc1l5hM1gNVEWHYJ1vr/BOrBaxHP5+FDrYdezZpi6eHbuhV3PfKKEiCnHQspYfTN7MYV1Za50B1EW8xYGG8akj44rGsnmC4aAjWSpWCw6nqeMzyB52OiA9WFyc7su2fKeMrB+rI5YSNJRKsQONorVA60/SsUr3VGVgXVjbdPPapEiZvVJ6xXWgW3aTSZly87+BhvAauzyO9gEZmKwSr8PNpI1Tb8wjbsXbCR7afoVcd56hV3K+BwCBoPBYH/DntCZZzz1A5uaAAAAAElFTkSuQmCC”
}

…or run this script (again includes several ways to invoke the same action)

./10-maven-action-qr-gen-run.sh

Want to try some of this live?

Then go here and enjoy!
