Framework Routers and Linking

The Router

// posts
export const PostRoutes: RouterConfig = [{
    path: '/posts',
    component: PostListComponent,
    children: [
        { path: ':id', component: PostComponent },
        { path: '', component: PostListComponent }
    ]
}];

Angular’s router syntax is very clear. It’s TypeScript, which adds a bit of unique flavour, but it’s clear and readable. The only thing that complicates or undermines the router is that recommended usage seems to be to have pieces of RouterConfig for app sections scattered throughout the app. Having the site’s entire route structure visible upfront can be helpful to get an understanding and overview. Whether these should be managed centrally or separated to areas of their concern is pretty subjective and not really worthy of criticism. Like many framework choices this one is very much open to interpretation.

Simple Links

<a routerLink="/about">About</a>
<a routerLink="/posts">Posts</a>

Router links are clear as well, with custom attributes to handle the actual path. This is a not uncommon solution. It’s simple and short, without a lot of extra fluff added.

Dynamic Links

<li *ngFor="let post of posts">
    <a [routerLink]="['/posts', post.id]">{{post.title}}</a>
</li>

Unfortunately it’s at this point that Angular 2 descends into special syntax soup. Let me just say subjectively and completely as a matter of opinion: this is gross. I know there are reasons and meaning and I know that’s how Angular has always operated, but… ew.

On a more objective note, this is actually not supported by default. Not all components can be routed like this off the bat. They need to be set up as an ActivatedRoute through the linked component’s constructor, and the linking component needs to have a shouty directive added to it as well. Why this isn’t default behaviour is something of a mystery and I’m sincerely concerned I’ve missed something.

I get the feeling that if I’m wrong, someone will let me know…

The Router

FlowRouter.route(‘/’, {
    name: ‘App.home’,
    action() {
        BlazeLayout.render(‘App_body’, {main: ‘app_rootRedirector’  });
    }
});

FlowRouter.route(‘/about’, {
    name: ‘About’,
    action() {
        BlazeLayout.render(‘App_body’, {main: ‘About_page’});
});
});

FlowRouter.route('/posts', {
    name: 'Posts.list',
    action() {
        BlazeLayout.render('App_body', { main: 'Post_list_page' });
    }
});

FlowRouter.route('/posts/:_id', {
    name: 'Posts.show',
    action() {
        BlazeLayout.render('App_body', { main: 'Lists_show_page' });
    }
});

Meteor is unusual in that there isn’t a single router. There are two. I initially focused on Iron Router because my reading suggested it was the “default” for Meteor. However, Meteor’s official guides use Flow, so I’ve changed tracks. There seems to be a lot of discussion back and forth about which one to use. I have to say in advance I count this against Meteor. This is exactly the sort of decision I don’t want to be making in a framework.

I also have to admit, and this is highly subjective, that I don’t like Meteor’s structure on this. It feels like each FlowRouter.route() is doing way too much. Most of all this reminds me of the basic implementation of routing in the Laravel framework.

Route::get('/posts', function () {
    return Posts::all();
});

However, that usage is only really intended as a naive illustration or a specific case. In actual usage on any reasonable system you would link to a controller@method structure much more often. Meteor doesn’t seem to have that potential for improvement. Note that the competing Iron Router doesn’t actually change this. Its structure is the same.

Note also that there is no nesting in the posts route, no programmatic logical connection between that route and its children.

Of all the frameworks, Meteor’s router has been the hardest to come to grips with. Finding documentation of the cases I wanted to cover, which seemed very reasonable, was not simple.

And perhaps I’m out of line, but the casing and structure seem to be all over the shop, and pretty hard to like. It might just be a poorly written example, but if so it’s a poorly written example from the official docs.

Simple Links

<a href="{{pathFor route='About'}}">About</a>
<a href="{{pathFor route='Posts.list'}}">Posts</a>

Though the usage of a simple handwritten url would be perfectly valid, this is considered more maintainable. Unfortunately, the syntax shown above isn’t included by default, and needs to be installed. This seems like a surprising omission. Meteor’s syntax for this should be familiar to many - it uses Spacebars, a variant of Handlebars.

Dynamic Links

{{#each list in lists}}
  <a href="{{pathFor ‘Lists.show’ _id=list._id}}">{{list.name}}</a>
{{/each}}

Again, this is Handlebars style syntax, which some will love and some will hate. And again, this pathFor is not part of a default Meteor install. I’d be interested to see if the pathFor binding is doing any more than string generation, or if it actually facilitates any sort of watcher on the link. But that’s out of the scope of this article.

The Router

Router.map(function() {
    this.route('about');
    this.route('posts', function() {
        this.route('show', {path: ':post_id'});
    });
});

Ember’s router is impressive in its brevity. Ember has a rather unique object entity called the Route. This is simply the object connected to any given URL pattern, and handles lifecycle hooks, model data, etc. Ember has extremely rigid naming conventions that enforce things like template names and project structure, so in this case, for example, there is a Route that lives in app/routes/about.js. Because this must be the file backing this url there’s no need to specify.

This implied nature is a blessing for those who know Ember’s conventions and requirements, but may well be a burden on people who don’t. There’s no explicit statement about what method or module handles the about route, where it gets its data from, or how it functions. There is no explicit statement about what template is used.

Simple Links

{{#link-to 'about'}}About{{/link-to}}
{{#link-to 'posts'}}Posts{{/link-to}}

The syntax for links is similar to Meteor, again due to the Handlebars-derived templating system. This is the “link-to helper”. This differs wildly from the land of JSX or component-included templates, but some people prefer a more separated strict MVC pattern.

Ember’s draconian conventions, strong opinions and forced separation of concerns is either its biggest benefit or a major flaw.

Dynamic Links

{{#each model as post}}
    <li>{{#link-to 'posts.show' post}}posts{{/link-to}}</li>
{{/each}}

Again, highly subjective whether this is clean or not (I like it) but there is a more objective benefit. In this case we’ve passed the post object through to the link-to helper. Because Ember now has a model for that route it does not need to run the model hook when it makes that transition. This means the initial XHR call to get the posts collection will be the first and last one that needs to be made. A nice default behaviour I believe not supported by the other frameworks without explicit setting and state management.

The Router

render((
<Router history={hashHistory}>
    <Route path="/" component={App}>
        <IndexRoute component={Home} />
        <Route path="about" component={About} />
        <Route path="posts" component={PostList}>
            <Route path=":id" component={PostShow}>
        </Route>
    </Route>
</Router>
), document.body)

There’s no way I can find to say this objectively. I think JSX is awful. I think this is gross. It violates the principles of good software development I’ve used all my career, and IMO just looks plain ugly. Everything about this makes me cringe. React is a fantastic library but this XML nonsense is weird. There is an alternative syntax that will bind down to JSX later, but I wanted to stick with idiomatic standards, and this is it. May God have mercy on its soul.

It’s also a mystery to me why what is essentially internal config has to “render”. And even more mysterious why config needs to render on a specified DOM element.

Simple Links

<ul>
    <li><Link to="/about">About</Link></li>
    <li><Link to"/posts">Posts</Link></li>
</ul>

Atypically, but not uniquely, React replaces out the entire anchor tag with a custom one. Again, not much to say about this.

Dynamic Links

{this.state.posts.map(user => (
<li key={post.id}>
    <Link to={`/posts/${post.id}`}>{post.title}</Link>
</li>
))}

Much like Angular 2’s example, the clarity of this gets a little bit lost in slightly esoteric syntax. Though in fairness it’s more ES6 than it is React. This is solid use of ES6 template literals. It’s obvious enough at a glance what it’s going for. It may not be everyone’s cup of tea, but it’s clear and contemporary.

The Router

router.map({
    '/': {component: HomePage},
    '/about': {name: 'about', component: About},
    '/posts': {
        name: 'postList',
        component: PostList,
        subRoutes: {
            '/:postId': {name: 'post', component: ShowPost}
        }
    }
})

Vue’s router is clean and easy to read. It does a nice job of effectively tying together a route with an object that contains the stuff it needs, particularly a component. Like Angular 2 it is explicitly nesting the subroutes, which is a definite preference.

The example I’ve shown is a simple style, but Vue can also be set up to lazy-load components from its routes. However, this is largely based on Webpack’s code splitting functionality.

Simple Links

<a v-link="{ path: '/about' }">About</a>
<a v-link="{ path: '/posts' }">Posts</a>

Again not unlike Angular’s approach, Vue uses a custom attribute to control the route link.

Dynamic Links

<li v-for="post in posts">
    <a v-link="{ name: 'post', params: { postId: post.id }}”>{{post.title}}</a>
</li>

The Angular is strong with this one, too, particularly in the syntax of the loop itself. The structure of the link makes perfect sense thanks to the use of the named route. Note that the same could have been done with the simple links above, using a name instead of a path.

The Router

config.map([
    { route: ['', 'home'], name: 'home', moduleId: 'home/index' },
    { route: 'about', name: 'about', moduleId: 'about/index', nav: true },
    { route: 'posts', name: 'postList', moduleId: 'post/index', nav: true },
    { route: 'posts/:postId', name: 'postShow', moduleId: 'post/show' },
]);

This is pretty decent. Only two things aren’t obvious. First of all, what’s the moduleId? None of the examples or documentation actually explain it. It’s taken for granted in Aurelia Land and used without explanation. A substantial amount of searching turns out that it’s specifically a view/viewmodel pairing.

This is the only framework that did not support explicit nesting. You can see the postList and postShow routes are on the same level. Objectively that doesn’t make a huge difference, but it can remove some optimisation as well as making the structure a little less clear.

Of note is the nav: true, which I left in place despite being out of scope. This key tells Aurelia what the top level navigation elements will be, and facilitates this capability:

<li repeat.for="row of router.navigation">
    <a href.bind="row.href">${row.title}</a>
</li>

Quite a nice piece of default behaviour out of the box.

Simple Links

<a route-href="route: about">About</a>
<a route-href="route: posts">Posts</a>

Aurelia’s routing is nice and clean. It explicitly states some of the things Ember users have to infer. But the linking process is oddly messy and unclear. Should you use href.bind? Or route-href? The latter seems typically preferred, with the former being used for internally generated links.

Dynamic Links

<li repeat.for="post of posts">
    <a route-href="route: post, params.bind: { postId: post.id }”>${post.title}</a>
</li>

This is very similar to the Vue example shown above. In fact I copy and pasted the Vue example and just changed the syntax. To be honest, that was the only way I was able to do so. I’ve pieced this syntax together from disparate examples, as the documentation doesn’t do a particularly great job of covering it.
