Understand Protocols — iOS

I’m not sure why many developers (even some senior developers) confuse Protocols with Object and Struct.

You can think of Protocols as a superclass with some rules. When you conform to that class you’ll have to simply obey those rules. In this case these rules can be methods and properties. Let’s look at an example so you’ll get a clear idea.

Let’s define our Protocol first.

Now you see the main difference between a Class and Protocol. You don’t implement your methods here in Protocol. It’s simply just defined.

Let’s create a Cat class now.

Now conform the Cat class to the Animal protocol as below

Oops but the compiler throws an error yeah?

Playground execution failed: error: Protocols.playground:4:7: error: type ‘Cat’ does not conform to protocol ‘Animal’
class Cat : Animal{
^
Protocols.playground:1:10: note: protocol requires function ‘stop()’ with type ‘() -> ()’; do you want to add a stub?
func stop()

Error message is clear right? It wants you to conform to the protocol. That means you need to implement the methods in the Protocol. Let’s see how to do it.

Cool! now there is no error. Let’s create Dog class and conform to the Animal Protocol just like we did for Cat.

This way you can make sure that all the classes that are conforming to the protocol will have the same set of methods implemented no matter what. You may ask, “isn’t it polymorphism?”. The answer is YES!

Multiple Protocols

Now you know how to create and conform to a protocol. But can you conform to multiple Protocols? Yes you can Checkout the example below.

Now in the above example the Cat class conforms to both Animal and Eye protocol. As you may have expected it has to conform to both the protocols no matter what.

Properties in Protocol

Now we know that we can add methods in protocol, so what about properties? Yes we can add them too. Look at the example below.

Here we have declared a property isIdle. You need to make sure that the property you declare in the protocol is having a getter and setter. Else you might end up with compiler errors.

Now let’s see how it’ll affect the Cat class when we are conforming.

Cool yeah? Let’s add some logic to our Cat class.

Now our Cat class looking complete.

Group with extension

Swift provides us with a option to group all the methods from a Protocol into a block. It’ll increase the readability of the code base. Look at the example below.

Looks neat yeah?

Creating Objects from Protocols?

Obviously the next question would be, can you create objects from protocol? Answer would be no. Same as you can’t create objects from an interface in Java.

But you can group the objects that has conformed to a protocol in an Array as below.

As you can see above animalsArray would only take objects that are conforming to the Animal protocol.

Hope it helped somebody somewhere in need. Good luck!

Don’t forget to read the Part II here (Protocol Extensions — iOS)
