A Simple Custom Theme on Magento 2

There are lots of blogs and articles that gives plenty information about Magento themes. This blog is my version of simplest steps to change logo on your Magento 2 store frontend using a simple custom theme.

Create a <vendor> folder under /magento/app/design/frontend

I named it Demostore.

Create a custom theme <theme> folder under /magento/app/design/frontend/Demostore

I named it SampleTheme.

Structure should be look like these:
magento/app/design/frontend/Demostore/SampleTheme

Make three files under SampleTheme folder

  • composer.json
  • registation.php
  • theme.xml .

Extact these three files composer.json, registation.php, theme.xml from magento blank theme 0r magento luma theme.

If you have composer based Magento 2 appliacation or if you got the zip, all languages, modules, themes will be under vendor/magento. So, Blank or luma theme can be found at vendor/magento/theme-frontend-blank or vendor/magento/theme-frontend-luma respectively.

Create these folders under /SampleTheme —

$ mkdir Magento_Theme media web etc

Structure should be like under /SampleTheme :-

SampleTheme/ →

composer.jason

registation.php

theme.xml

etc/

media/

web/

Magento_Theme/

  1. For composer.json, “name” should reflect the Demostore/SampleTheme

2. Edit registation.php to reflect correct theme path as shown below:

3. copy code into theme.xml.

<theme xmlns:xsi=”http://www.w3.org/2001/XMLSchema-instance" xsi:noNamespaceSchemaLocation=”urn:magento:framework:Config/etc/theme.xsd”>
<title>Demostore SampleTheme</title> <! — your theme’s name →
<parent>Magento/blank</parent> <! — the parent theme, in case your theme inherits from an existing theme →
<media>
<preview_image>media/preview.jpg</preview_image> <! — the path to your theme’s preview image →
</media>
</theme>

4. In etc folder create view.xml with following code:

<?xml version="1.0"?>
<!--
/**
* Copyright © 2016 Magento. All rights reserved.
* See COPYING.txt for license details.
*/
-->
<view xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:noNamespaceSchemaLocation="urn:magento:framework:Config/etc/view.xsd">
<media>
<images module="Magento_Catalog">
<image id="bundled_product_customization_page" type="thumbnail">
<width>140</width>
<height>140</height>
</image>
<image id="cart_cross_sell_products" type="thumbnail">
<width>152</width>
<height>188</height>
</image>
<image id="cart_page_product_thumbnail" type="small_image">
<width>110</width>
<height>160</height>
</image>
<image id="category_page_grid" type="small_image">
<width>240</width>
<height>300</height>
</image>
<image id="category_page_list" type="small_image">
<width>240</width>
<height>300</height>
</image>
<image id="customer_account_my_tags_tag_view" type="small_image">
<width>100</width>
<height>100</height>
</image>
<image id="customer_account_product_review_page" type="image">
<width>285</width>
<height>285</height>
</image>
<image id="customer_shared_wishlist" type="small_image">
<width>113</width>
<height>113</height>
</image>
<image id="gift_messages_checkout_small_image" type="small_image">
<width>75</width>
<height>75</height>
</image>
<image id="gift_messages_checkout_thumbnail" type="thumbnail">
<width>100</width>
<height>100</height>
</image>
<image id="mini_cart_product_thumbnail" type="thumbnail">
<width>78</width>
<height>78</height>
</image>
<image id="new_products_content_widget_grid" type="small_image">
<width>240</width>
<height>300</height>
</image>
<image id="new_products_content_widget_list" type="small_image">
<width>270</width>
<height>270</height>
</image>
<image id="new_products_images_only_widget" type="small_image">
<width>78</width>
<height>78</height>
</image>
<image id="product_base_image" type="image">
<width>265</width>
<height>265</height>
</image>
<image id="product_comparison_list" type="small_image">
<width>140</width>
<height>140</height>
</image>
<image id="product_page_image_large" type="image"/>
<image id="product_page_image_medium" type="image">
<width>700</width>
<height>700</height>
</image>
<image id="product_page_image_small" type="thumbnail">
<width>90</width>
<height>90</height>
</image>
<image id="product_page_main_image" type="image">
<width>700</width>
<height>700</height>
</image>
<image id="product_page_main_image_default" type="image">
<width>700</width>
<height>700</height>
</image>
<image id="product_page_more_views" type="thumbnail">
<width>90</width>
<height>90</height>
</image>
<image id="product_stock_alert_email_product_image" type="small_image">
<width>76</width>
<height>76</height>
</image>
<image id="product_small_image" type="small_image">
<width>135</width>
<height>135</height>
</image>
<image id="product_thumbnail_image" type="thumbnail">
<width>75</width>
<height>75</height>
</image>
<image id="recently_compared_products_grid_content_widget" type="small_image">
<width>240</width>
<height>300</height>
</image>
<image id="recently_compared_products_images_names_widget" type="thumbnail">
<width>75</width>
<height>90</height>
</image>
<image id="recently_compared_products_images_only_widget" type="thumbnail">
<width>76</width>
<height>76</height>
</image>
<image id="recently_compared_products_list_content_widget" type="small_image">
<width>270</width>
<height>207</height>
</image>
<image id="recently_viewed_products_grid_content_widget" type="small_image">
<width>240</width>
<height>300</height>
</image>
<image id="recently_viewed_products_images_names_widget" type="small_image">
<width>75</width>
<height>90</height>
</image>
<image id="recently_viewed_products_images_only_widget" type="small_image">
<width>76</width>
<height>76</height>
</image>
<image id="recently_viewed_products_list_content_widget" type="small_image">
<width>270</width>
<height>270</height>
</image>
<image id="related_products_list" type="small_image">
<width>140</width>
<height>140</height>
</image>
<image id="review_page_product_image" type="small_image">
<width>285</width>
<height>285</height>
</image>
<image id="rss_thumbnail" type="thumbnail">
<width>75</width>
<height>75</height>
</image>
<image id="sendfriend_small_image" type="small_image">
<width>75</width>
<height>75</height>
</image>
<image id="shared_wishlist_email" type="small_image">
<width>135</width>
<height>135</height>
</image>
<image id="side_column_widget_product_thumbnail" type="thumbnail">
<width>75</width>
<height>90</height>
</image>
<image id="upsell_products_list" type="small_image">
<width>140</width>
<height>140</height>
</image>
<image id="wishlist_sidebar_block" type="thumbnail">
<width>75</width>
<height>90</height>
</image>
<image id="wishlist_small_image" type="small_image">
<width>113</width>
<height>113</height>
</image>
<image id="wishlist_thumbnail" type="small_image">
<width>240</width>
<height>300</height>
</image>
</images>
</media>
<vars module="Magento_Catalog">
<!-- Gallery and magnifier theme settings. Start -->
<var name="gallery">
<var name="nav">thumbs</var> <!-- Gallery navigation style (false/thumbs/dots) -->
<var name="loop">true</var> <!-- Gallery navigation loop (true/false) -->
<var name="keyboard">true</var> <!-- Turn on/off keyboard arrows navigation (true/false) -->
<var name="arrows">true</var> <!-- Turn on/off arrows on the sides preview (true/false) -->
<var name="caption">false</var> <!-- Display alt text as image title (true/false) -->
<var name="allowfullscreen">true</var> <!-- Turn on/off fullscreen (true/false) -->
<var name="navdir">horizontal</var> <!-- Sliding direction of thumbnails (horizontal/vertical) -->
<var name="navarrows">true</var> <!-- Turn on/off on the thumbs navigation sides arrows(true/false) -->
<var name="navtype">slides</var> <!-- Sliding type of thumbnails (slides/thumbs) -->
<var name="transition">
<var name="effect">slide</var> <!-- Sets transition effect for slides changing (slide/crossfade/dissolve) -->
<var name="duration">500</var> <!-- Sets transition duration in ms -->
</var>
<var name="fullscreen">
<var name="nav">thumbs</var> <!-- Fullscreen navigation style (false/thumbs/dots) -->
<var name="loop">true</var> <!-- Fullscreen navigation loop (true/false/null) -->
<var name="arrows">false</var> <!-- Turn on/off arrows on the sides preview in fullscreen (true/false/null) -->
<var name="caption">false</var> <!-- Display alt text as image title in fullscreen(true/false) -->
<var name="navdir">horizontal</var> <!--Sliding direction of thumbnails in fullscreen(horizontal/vertical) -->
<var name="navtype">slides</var> <!-- Sliding type of thumbnails (slides/thumbs) -->
<var name="transition">
<var name="effect">dissolve</var> <!-- Sets transition effect for slides changing (slide/crossfade/dissolve) -->
<var name="duration">500</var> <!-- Sets transition duration in ms -->
</var>
</var>
</var>
<var name="magnifier">
<var name="fullscreenzoom">20</var> <!-- Zoom for fullscreen (integer)-->
<var name="top"></var> <!-- Top position of magnifier -->
<var name="left"></var> <!-- Left position of magnifier -->
<var name="width"></var> <!-- Width of magnifier block -->
<var name="height"></var> <!-- Height of magnifier block -->
<var name="eventType">hover</var> <!-- Action that atcivates zoom (hover/click) -->
<var name="enabled">false</var> <!-- Turn on/off magnifier (true/false) -->
</var>
<var name="breakpoints">
<var name="mobile">
<var name="conditions">
<var name="max-width">767px</var>
</var>
<var name="options">
<var name="options">
<var name="navigation">dots</var>
</var>
</var>
</var>
</var>
<!-- end. Gallery and magnifier theme settings -->
<var name="product_small_image_sidebar_size">100</var>  <!-- Override for small product image -->
<var name="product_base_image_size">275</var> <!-- Override for base product image -->
<var name="product_base_image_icon_size">48</var> <!-- Base product image icon size -->
<var name="product_list_image_size">166</var>           <!-- New Product image size used in product list -->
<var name="product_zoom_image_size">370</var> <!-- New Product image size used for zooming -->
<var name="product_image_white_borders">0</var>
</vars>
<vars module="Magento_Bundle">
<var name="product_summary_image_size">58</var> <!-- New Product image size used for summary block-->
</vars>
<vars module="Js_Bundle">
<var name="bundle_size">1MB</var>
</vars>
<exclude>
<item type="file">Lib::jquery/jquery.min.js</item>
<item type="file">Lib::jquery/jquery-ui-1.9.2.js</item>
<item type="file">Lib::jquery/jquery.ba-hashchange.min.js</item>
<item type="file">Lib::jquery/jquery.details.js</item>
<item type="file">Lib::jquery/jquery.details.min.js</item>
<item type="file">Lib::jquery/jquery.hoverIntent.js</item>
<item type="file">Lib::jquery/colorpicker/js/colorpicker.js</item>
<item type="file">Lib::requirejs/require.js</item>
<item type="file">Lib::requirejs/text.js</item>
<item type="file">Lib::date-format-normalizer.js</item>
<item type="file">Lib::legacy-build.min.js</item>
<item type="file">Lib::mage/captcha.js</item>
<item type="file">Lib::mage/dropdown_old.js</item>
<item type="file">Lib::mage/list.js</item>
<item type="file">Lib::mage/loader_old.js</item>
<item type="file">Lib::mage/webapi.js</item>
<item type="file">Lib::mage/zoom.js</item>
<item type="file">Lib::mage/translate-inline-vde.js</item>
<item type="file">Lib::mage/requirejs/mixins.js</item>
<item type="file">Lib::mage/requirejs/static.js</item>
<item type="file">Magento_Customer::js/zxcvbn.js</item>
<item type="file">Magento_Catalog::js/zoom.js</item>
<item type="file">Magento_Ui::js/lib/step-wizard.js</item>
<item type="file">Magento_Ui::js/form/element/ui-select.js</item>
<item type="file">Magento_Ui::js/form/element/file-uploader.js</item>
<item type="file">Magento_Ui::js/form/components/insert.js</item>
<item type="file">Magento_Ui::js/form/components/insert-listing.js</item>
<item type="directory">Magento_Ui::js/timeline</item>
<item type="directory">Magento_Ui::js/grid</item>
<item type="directory">Magento_Ui::js/dynamic-rows</item>
<item type="directory">Magento_Ui::templates/timeline</item>
<item type="directory">Magento_Ui::templates/grid</item>
<item type="directory">Magento_Ui::templates/dynamic-rows</item>
<item type="directory">Magento_Swagger::swagger-ui</item>
<item type="directory">Lib::modernizr</item>
<item type="directory">Lib::tiny_mce</item>
<item type="directory">Lib::varien</item>
<item type="directory">Lib::jquery/editableMultiselect</item>
<item type="directory">Lib::jquery/jstree</item>
<item type="directory">Lib::jquery/fileUploader</item>
<item type="directory">Lib::css</item>
<item type="directory">Lib::lib</item>
<item type="directory">Lib::extjs</item>
<item type="directory">Lib::prototype</item>
<item type="directory">Lib::scriptaculous</item>
<item type="directory">Lib::less</item>
<item type="directory">Lib::mage/adminhtml</item>
<item type="directory">Lib::mage/backend</item>
</exclude>
</view>

NOTE: You can extract file from luma /blank theme. No changes require for them.

5. Under media folder add preview.jpg. This file is for structure only and will not be visible anywhere on the frontend.

6. Under web folder make three folders css, images, js

$ mkdir web/css web/images web/js

Since we are just planning to change the logo, we don’t really have to make any files in css and js folder but they are only for completeness of the custom theme structure.

In images folder, put the logo that you want to display on front page. I put woody.jpeg :)

7. In Magento_Theme folder create layout folder : Magento_Theme/layout

Make file defult.xml under layout folder.

Please change the logo name to woody.jpeg or <your log name>.

That’s it. Final structure should be like this.

The next part is to configure this theme in magento/admin.

  • Configure new theme.
  • Go to CONTENT → Configuration. It will shows you Design configuration page.
  • Edit main store Theme. Change new theme as Default Store Theme.
  • Click on save configuration. You will probably get system message on screen.
  • Click on Cache Management link. you will redirect to the page :
  • Select invalid cache and refresh it. Now go to the frontend home page and your logo will be changed to new theme.

Yupee Dee…!! Woody is on the home page…!!!

NOTE: There are a few additional things that you may have to do, if the log is not updated by following just these steps.
* Remove all folders from pub/static
* Remove the content from var/cache var/di var/page_cache var/view_processed
* Run php bin/magento setup:static-content:deploy
* Run php bin/magento setup:upgrade
* Run php bin/magento setup:di:compile (if you see that message on the command prompt)
* Finally, restart the apache server

If you want to save yourself from all the manual steps given below, you can use the mage-scripts github repository and run a shell script to do exactly this.
