IoT with an ESP32, InfluxDB and Grafana

Part 1: Streaming Locally

Thomas Bruen
Jan 29, 2018 · 8 min read
Image for post
Image for post

I’ve been moving into more IoT / connected devices recently. There are a load of platforms but a lot of them seem very closed-off or limited in scope (Losant being an interesting exception). At the other end, there’s something like AWS IoT, which has all sorts of benefits (scalability, machine learning, big data) but with a steeper learning curve and the very present fear that I will accidentally rack up a huge bill.

I’ve used InfluxDB before for logging data locally, and am pretty impressed with its performance. For another project, I’ve been streaming data over BLE every 20ms while querying batches of data with a Python process, and it’s performed admirably with very low latency. It was also convenient for running machine learning on the data (offline training, and real-time execution). That project also used an ESP32 MCU, which I’ve found great for prototyping, though they’re playing catch-up with the documentation and codebase.

I thought that using InfluxDB for an IoT application would be a good introduction to streaming data over WiFi and some less intimidating cloud stuff. This was broken up into three parts:

  1. Sending data over HTTP to an InfluxDB server on my Mac
  2. As above, but HTTPS
  3. Deploying the server on AWS and streaming to it.

Strap in.

Image for post
Image for post

Setting up InfluxDB

InfluxDB is a NoSQL database explicitly for time-series data (i.e. all the data I ever work with). For the first two stages, I ran InfluxDB on my Mac: homebrew install influxdb. The current version is 1.4.2; it seems there were some major changes recently and the Python client claims not to support it, but in practice I’ve had no issues querying data.

To start the server, run influxd (no need to sudo on a Mac). In another terminal tab, use the command line interface to set-up a database:

$ influx
Connected to http://localhost:8086 version v1.4.2
InfluxDB shell version: v1.4.2

If you switch back to the tab running the daemon, you should see the corresponding message appearing:

Image for post
Image for post

When you are running embedded devices without a serial port for displaying error messages, checking this window can be useful for figure out what’s going wrong.

Now, we can add some data using the HTTP API, which requires a string containing the measurement name, tag sets and field sets (the space in the string is what separates tags and fields):

curl -i -XPOST ‘http://localhost:8086/write?db=esp32_tst' — data-binary “dummy,device=mac field_1=69

should return HTTP/1.1 204 No Content , meaning a successful write (a 404 probably means you haven’t created the database, and a 400 means you didn’t write a valid string). We create a tag called “device” and a field called, creatively, “field_1”. More info on tags and fields here. We can double check by querying the data in the CLI:

> use esp32_tst
Using database esp32_tst
> SELECT * FROM dummy
name: dummy
time device field_1
---- ------ -------
1516658590825700342 mac 69

There’s more configuration of InfluxDB later, but this will do for now.

Arduino Code

Image for post
Image for post

I put together a simple library for writing data using the HTTP API. It’s a pretty thin wrapper for the HTTP Client library, but makes life easier. All it requires is the local IP of the where the InfluxDB server is running(in this case, my Mac’s address, which you can find using ipconfig getifaddr en0), and the port (we’re using the default of 8086). It also has options for authorisation and HTTPS, which we’ll get to later.

You can test it works by running the WritePoints.ino example, and setting your own values for WiFi credentials, and database name (make sure the database exists or you’ll get a 404 error). You can see the data coming in on the daemon window, or use the CLI to see what new data has come in:

USE esp32_tst
SELECT * FROM test WHERE time > now() - 5s
name: test
time count new_tag random_var
---- ----- ------- ----------
1517223799607069455 91 Yes 0.802
1517223800492976221 92 Yes 0.263
1517223801509686351 93 Yes 0.092
1517223802510211739 94 Yes 0.322
1517223803492709390 95 Yes 0.765


Image for post
Image for post

By default, anyone can write to the database. To make sure we know who the data are coming from, we can limit privileges by adding users. In the influx CLI, create an admin user, and then another user:


Then, save a config file to a location of your choosing, as a .conf file. Edit theauth-enabled value of the config file to true (it’s under the [http] header), and restart the InfluxDB daemon, with the config file as an argument: influxd -config /path/to/conf/file/<configname.conf> . Now, if you enter the influx CLI as usual and try and run any command, you’ll get the following message: ERR: unable to parse authentication details. Instead, we need to log in to the CLI: influx -username tom -password <password> . Note that running SHOW DATABASES won’t display anything, because the previous one we made was made as the root user.

If you create the database and try running the same Arduino code as before, unsurprisingly you’ll see a 401 (unauthorised) error. In the sketch, un-uncomment the influx.authorise line and add your details, and you should be back to a successful 204 code.

TLS Encryption

Image for post
Image for post
Jared is watching.

Authorisation might be a bit safer, but it’s still possible for other people to intercept and read the data you’re sending. To get around this, we can encrypt it using TLS, sending via HTTPS. The HTTPClient library can do this, using the mbed TLS library which Espressif has conveniently ported to the ESP32 (it’s not an easy task).


We are going to be using a self-signed certificate, as opposed to sending it to Symantec or someone to approve it. This means our data will be encrypted, but not verified (that we can’t officially prove who we say we are). And that’s fine, but it did cause me a lot of grief for a long time. We have to modify the source slightly, by changing a line in ssl_client.cpp from the WiFiClientSecure library:

// mbedtls_ssl_conf_authmode(&ssl_client->ssl_conf, MBEDTLS_SSL_VERIFY_REQUIRED);
mbedtls_ssl_conf_authmode(&ssl_client->ssl_conf, MBEDTLS_SSL_VERIFY_NONE); //REQUIRED FOR SELF-SIGNED CERT

Create your self-signed certificate according to InfluxData’s instructions. I made a directory in usr/local/etc/sslto save them in, but I guess anywhere out the way is fine ¯\_(ツ)_/¯. In your .conf file, just down from the auth-enabled setting, set the following:

https-enabled = true
https-certificate = "/usr/local/etc/ssl/,<cert-name>.crt"
https-private-key = "/usr/local/etc/ssl/<key-name>.key"

Restart the daemon, making sure to add the config file argument. If you try and access the CLI, you’ll get an error because it’s still trying to use HTTP:

influx -username tom -password dontthinksomate
Failed to connect to https://localhost:8086: Get http://localhost:8086/ping: net/http: HTTP/1.x transport connection broken: malformed HTTP response "\x15\x03\x01\x00\x02\x02"
Please use the -ssl flag to connect using SSL.

As it says, we need to use the -ssl flag. Because our certificate is self-signed, we also need to use the -unsafeSsl flag, which they seemed to hide from the documentation. influx -ssl -unsafeSsl -username tom -password comeon should let you back in as usual.

Image for post
Image for post
Unlikely to be your actual certificate.

If you try and run the existing Arduino sketch, InfluxDB will throw a TLS handshake error. To start using HTTPS, you need to copy your certificate into the InfluxCert.hpp template, making sure to include the “begin/end certificate” lines, newlines, and the backslash to let the compiler know this is one big string. Also make sure to #include “InfluxCert.hpp" and uncomment the influx.addCertificate(ROOT_CERT); line. Once compiled, you should get the same old 204 response. If you get anything mentioning an EOF error, that probably means you’ve messed up copying/ formatting the certificate in InfluxCert.hpp. If you get “remote error: tls: bad certificate”, that means ssl_client.cpp wasn’t changed correctly and it’s trying to verify the certificate.


Grafana is a popular open-source time series visualisation/ analytics tool, which supports integration with InfluxDB. (InfluxData makes a similar program called Chronograf, which I was a couple of years ago and wasn’t so keen on, but I should give it another try because a lot will have changed and I find the Grafana user experience quite unintuitive).

brew update
brew install grafana
brew tap homebrew/services

Start Grafana using one of these:

brew services start grafanagrafana-server --config=/usr/local/etc/grafana/grafana.ini --homepath /usr/local/share/grafana

If you’ve already got Grafana installed, then make sure you update because there was a problem with using only CA certs (it insists on a client certificate and key and according to the Github Issue I can’t find anymore, it was also a security flaw).

In your browser, head to http://localhost:3000/login (3000 being Grafana’s default port), and log in as admin with password admin. Obviously you should change this password: go to your profile by navigating to the Grafana logo in the top left.

Add the data source by filling out the forms. Most of it is self-explanatory: make sure to tick the “With CA Cert” box, and then the Skip TLS Verification box (because ours is self-signed, remember). Also make sure to change the default URL to HTTPS.

Image for post
Image for post

On the Grafana menu on the top left, click on Dashboards and create a new one. Drag a graph into the hatched space, then click on the title, then edit to actually select what data to plot (weird, right?). I made a very basic query to plot the random variable generated in the Sketch. We’ll cover more things you can do later. You can remove predefined elements (such as mean aggregation, and group by time) by clicking on the left-hand part of the box. Clicking on the the top right of the window lets you control the time history, including a “refresh every” option at the bottom left of the menu, which periodically refreshes the plots so you see the new data coming in.

Image for post
Image for post

That’s it — remember to save the dashboard by clicking the flopp disk at the top, otherwise you’ll have to repeat it all next time you log in…
