Digit Emoji Predictor: Build UI for Deep Learning model in Notebook

Build a digit emoji predictor in Jupyter notebook by passing data between JavaScript & Python. Typically, JavaScripts are used for data visualization in notebooks, but it can also be used for prototyping front-end/UI for deep learning models.

Aravind Ramalingam
Apr 30 · 9 min read

Why the hell build UI in Notebook?

Share the Deep Learning model notebook with colleagues from different teams like Business, Data Science, Front End developer, DevOps for their opinion before the real software development takes place.

Jupyter notebook is meant for quick prototyping and everyone knows this but what many misses is we can also do a quick prototype of UI as well. Many data scientists are quick to start building the big deep learning model with whatever little data they have without even thinking about what they are developing and for whom 🤷‍♂️. Trust me, the first model you are satisfied with (based on the metrics like accuracy) won’t be deployed into production for various reasons like slow inference time, no on-device support, memory hogging blah blah.

Even experienced project/product managers sometimes won’t know what they really want so first try to get the workflow or pipeline agreement from all the players involved, even with this some things will slip through the crack. “ I am data scientist, My job is only to build ML models is not the right mindset, at least in my opinion.” A tad bit of knowledge in Business, Web development, DevOps can help you save a ton of time in trying to debug, or explain why the model/workflow you built is the best for business. Better to be jack of all trades here. BTW, this does not mean that you should take over the responsibilities of your colleagues. Just try to get a sense of what is happening outside your circle. In this post, Let me share an example of how creating a simple UI for input & output for deep learning model can help you see the cracks in your workflow and increase productivity.

Application

If you are not familiar with MNIST dataset then just know that you can build a Digit Emoji Predictor as the dataset contains greyscale images of hand-drawn digits, from zero through nine. So our UI is going to let the user draw a digit & display the corresponding emoji.

Digit Emoji Recognizer

I have trained the CNN Deep learning model using the pytorch, we will just download the model & weights from here. This is a simple model with 3 Conv blocks and 2 Fully connected layers. The Transformations used for this model are Resize & ToTensor. Upon calling the predict function on the image, we will get the predicted digit.

import torch
import torch.nn as nn
import torch.nn.functional as F
from torchvision import transforms

# Digit Recognizer model definition
class CNN(nn.Module):
def __init__(self):
super(CNN, self).__init__()
self.conv1 = nn.Conv2d(1, 32, kernel_size=5)
self.conv2 = nn.Conv2d(32, 32, kernel_size=5)
self.conv3 = nn.Conv2d(32,64, kernel_size=5)
self.fc1 = nn.Linear(3*3*64, 256)
self.fc2 = nn.Linear(256, 10)

def forward(self, x):
x = F.relu(self.conv1(x))
x = F.dropout(x, p=0.5, training=self.training)
x = F.relu(F.max_pool2d(self.conv2(x), 2))
x = F.dropout(x, p=0.5, training=self.training)
x = F.relu(F.max_pool2d(self.conv3(x),2))
x = F.dropout(x, p=0.5, training=self.training)
x = x.view(-1,3*3*64 )
x = F.relu(self.fc1(x))
x = F.dropout(x, training=self.training)
x = self.fc2(x)
return x



# Predict the digit given the tensor
def predict(image, modelName = 'mnist_model.pth'):

# Resize before converting the image to Tensor
Trfms = transforms.Compose([transforms.Resize(28), transforms.ToTensor()])

# Apply transformations and increase dim for mini-batch dimension
imageTensor = Trfms(image).unsqueeze(0)

# Download model from URL and load it
model = torch.load(modelName)

# Activate Eval mode
model.eval()

# Pass the image tensor by the model & return max index of output
with torch.no_grad():
out = model(imageTensor)
return int(torch.max(out, 1)[1])
import re, base64
from PIL import Image
from io import BytesIO

# Decode the image drawn by the user
def decodeImage(codec):

# remove the front part of codec

# base64 decode
byte_data = base64.b64decode(base64_data)

# Convert to bytes
image_data = BytesIO(byte_data)

# Convert to image & convert to grayscale
img = Image.open(image_data).convert('L')
return img
# Decode the image and predict the value
def decode_predict(imgStr):

# Decode the image
image = decodeImage(imgStr)

# Declare html codes for 0-9 emoji
emojis = [
"0️⃣",
"1️⃣",
"2️⃣",
"3️⃣",
"4️⃣",
"5️⃣",
"6️⃣",
"7️⃣",
"8️⃣",
"9️⃣"
]

# Call the predict function
digit = predict(image)

# get corresponding emoji
return emojis[digit]

UI

The HTML & CSS part are quite straight forward, the JavaScript lets the user draw inside the canvas and call functions via the buttons Predict & Clear. The Clear button cleans up the canvas and sets the result to 🤔 emoji. We will set up the Predict button JS function in the next section.

from IPython.display import HTML

html = """
<div class="outer">
<! -- HEADER SECTION -->
<div>
<h3 style="margin-left: 30px;"> Digit Emoji Predictor &#128640; </h3>
<br>
<h7 style="margin-left: 40px;"> Draw a digit from &#48;&#65039;&#8419; - &#57;&#65039;&#8419;</h7>
</div>

<div>
<! -- CANVAS TO DRAW THE DIGIT -->
<canvas id="canvas" width="250" height="250" style="border:2px solid; float: left; border-radius: 5px; cursor: crosshair;">
</canvas>

<! -- SHOW PREDICTED DIGIT EMOJI-->
<div class="wrapper1"> <p id="result">&#129300;</p></div>

<! -- BUTTONS TO CALL DL MODEL & CLEAR THE CANVAS -->
<div class="wrapper2">
<button type="button" id="predictButton" style="color: #4CAF50;margin:10px;"> Predict </button>
<button type="button" id="clearButton" style="color: #f44336;margin:10px;"> Clear </button>
</div>
</div>
</div>
"""


css = """
<style>
.wrapper1 {
text-align: center;
display: inline-block;
position: absolute;
top: 82%;
left: 25%;
justify-content: center;
font-size: 30px;
}
.wrapper2 {
text-align: center;
display: inline-block;
position: absolute;
top: 90%;
left: 19%;
justify-content: center;
}

.outer {
height: 400px;
width: 400px;
justify-content: center;
}

</style>
"""


javascript = """

<script type="text/javascript">
(function() {
/* SETUP CANVAS & ALLOW USER TO DRAW */
var canvas = document.querySelector("#canvas");
canvas.width = 250;
canvas.height = 250;
var context = canvas.getContext("2d");
var canvastop = canvas.offsetTop
var lastx;
var lasty;
context.strokeStyle = "#000000";
context.lineCap = 'round';
context.lineJoin = 'round';
context.lineWidth = 5;

function dot(x, y) {
context.beginPath();
context.fillStyle = "#000000";
context.arc(x, y, 1, 0, Math.PI * 2, true);
context.fill();
context.stroke();
context.closePath();
}

function line(fromx, fromy, tox, toy) {
context.beginPath();
context.moveTo(fromx, fromy);
context.lineTo(tox, toy);
context.stroke();
context.closePath();
}
canvas.ontouchstart = function(event) {
event.preventDefault();
lastx = event.touches[0].clientX;
lasty = event.touches[0].clientY - canvastop;
dot(lastx, lasty);
}
canvas.ontouchmove = function(event) {
event.preventDefault();
var newx = event.touches[0].clientX;
var newy = event.touches[0].clientY - canvastop;
line(lastx, lasty, newx, newy);
lastx = newx;
lasty = newy;
}
var Mouse = {
x: 0,
y: 0
};
var lastMouse = {
x: 0,
y: 0
};
context.fillStyle = "white";
context.fillRect(0, 0, canvas.width, canvas.height);
context.color = "black";
context.lineWidth = 10;
context.lineJoin = context.lineCap = 'round';
debug();
canvas.addEventListener("mousemove", function(e) {
lastMouse.x = Mouse.x;
lastMouse.y = Mouse.y;
Mouse.x = e.pageX - canvas.getBoundingClientRect().left;
Mouse.y = e.pageY - canvas.getBoundingClientRect().top;
}, false);
canvas.addEventListener("mousedown", function(e) {
canvas.addEventListener("mousemove", onPaint, false);
}, false);
canvas.addEventListener("mouseup", function() {
canvas.removeEventListener("mousemove", onPaint, false);
}, false);
var onPaint = function() {
context.lineWidth = context.lineWidth;
context.lineJoin = "round";
context.lineCap = "round";
context.strokeStyle = context.color;
context.beginPath();
context.moveTo(lastMouse.x, lastMouse.y);
context.lineTo(Mouse.x, Mouse.y);
context.closePath();
context.stroke();
};

function debug() {
/* CLEAR BUTTON */
var clearButton = $("#clearButton");
clearButton.on("click", function() {
context.clearRect(0, 0, 250, 250);
context.fillStyle = "white";
context.fillRect(0, 0, canvas.width, canvas.height);

/* Remove Result */
document.getElementById("result").innerHTML = "&#129300;";
});
$("#colors").change(function() {
var color = $("#colors").val();
context.color = color;
});
$("#lineWidth").change(function() {
context.lineWidth = $(this).val();
});
}
}());

</script>

"""


HTML(html + css + javascript)
UI for the Digit Emoji Predictor
/* PASS CANVAS BASE64 IMAGE TO PYTHON VARIABLE imgStr*/
var imgData = canvasObj.toDataURL();
var imgVar = 'imgStr';
var passImgCode = imgVar + " = '" + imgData + "'";
var kernel = IPython.notebook.kernel;
kernel.execute(passImgCode);
/* CALL PYTHON FUNCTION "decode_predict" WITH "imgStr" AS ARGUMENT */
function handle_output(response) {
/* UPDATE THE HTML BASED ON THE OUTPUT */
var result = response.content.data["text/plain"].slice(1, -1);
document.getElementById("result").innerHTML = result;
}
var callbacks = {
'iopub': {
'output': handle_output,
}
};
var getPredictionCode = "decode_predict(imgStr)";
kernel.execute(getPredictionCode, callbacks, { silent: false });
predictJS = """<script type="text/javascript">

/* PREDICTION BUTTON */
$("#predictButton").click(function() {
var canvasObj = document.getElementById("canvas");
var context = canvas.getContext("2d");

/* PASS CANVAS BASE64 IMAGE TO PYTHON VARIABLE imgStr*/
var imgData = canvasObj.toDataURL();
var imgVar = 'imgStr';
var passImgCode = imgVar + " = '" + imgData + "'";
var kernel = IPython.notebook.kernel;
kernel.execute(passImgCode);

/* CALL PYTHON FUNCTION "decode_predict" WITH "imgStr" AS ARGUMENT */
function handle_output(response) {
/* UPDATE THE HTML BASED ON THE OUTPUT */
var result = response.content.data["text/plain"].slice(1, -1);
document.getElementById("result").innerHTML = result;
}
var callbacks = {
'iopub': {
'output': handle_output,
}
};
var getPredictionCode = "decode_predict(imgStr)";
kernel.execute(getPredictionCode, callbacks, { silent: false });
});
</script>

"""
HTML(predictJS)
Wrong Predictions
Compare the images from Canvas and MNIST
import PIL.ImageOps

# Decode the image and predict the value
def decode_predict(imgStr):

# Decode the image
image = decodeImage(imgStr)

# Invert the image as model expects black background & white strokes
image = PIL.ImageOps.invert(image)

# Declare html codes for 0-9 emoji
emojis = [
"&#48;&#65039;&#8419;",
"&#49;&#65039;&#8419;",
"&#50;&#65039;&#8419;",
"&#51;&#65039;&#8419;",
"&#52;&#65039;&#8419;",
"&#53;&#65039;&#8419;",
"&#54;&#65039;&#8419;",
"&#55;&#65039;&#8419;",
"&#56;&#65039;&#8419;",
"&#57;&#65039;&#8419;"
]

# Call the predict function
digit = predict(image)

# get corresponding emoji
return emojis[digit]
Correct Digit Emoji Prediction

Conclusion

Now you can quickly share this notebook with everyone and ask for their opinion. Don’t forget to mention the caveat that this is an early prototype. Without much effort, we sort of replicated the functionalities of a web app. The biggest plus is we never left the comfort of notebook and potentially bridged the gap between Training & Test data.
