Predicting Selling Price | Regression Models | Cross Validation

In machine learning, there are classification and regression model. The different of the two is that classification predict the output (or y) as either yes or no, up or down, or some other categories. For example, in sentiment analysis, we want to know whether a review belongs to a good or a bad sentiment. However, in regression, the output that we want is the value, like what will be the price of the house.

In this vehicle price prediction, it is a good practice for the regression model. It contains several features where we need to prepare and we are also facing none normal distribution.

The aim of this article is to go through steps for doing regression analysis where we will compare several models and run them with cross-validation. So, stay tuned. Below is the list of what we will be covering.

# Outline of this articles

- Data Overview
- Data Visualization
- Data Preparation (Missing value and category data)
- Model Comparison and Selection (Linear Regression, Random Forest Regressor, Gradient Boosting Regressor, Extreme Gradient Boosting)
- Prediction

# 1. Data Overview

Kaggle has provided a data set for second hand vehicles’ prices. We are going to use this data for our project. The full data set contains 423,857 rows of data with 25 attributes. Let’s have a look at it.

import pandas as pd

import matplotlib.pyplot as plt

import seaborn as sns

import numpy as npdata = pd.read_csv('.../vehicles.csv')

pd.set_option('display.max_columns', 25)

data.info()

We can see that our data contain many missing values and mostly are object type of the categorial data. We are going to have a lot to do with data preparation. But before we go to that, we shall visualize our data.

# 2. Data Visualization

As we have longitude and latitude attributes, we can create geographically view from it.

`data.plot(kind=’scatter’, x=’long’, y=’lat’, `

alpha=0.4, figsize=(10,7))

Our data is collected mostly within the USA. We can see this from the geographical visualisation as majority of the data are located in the USA area, and only few of them are scattered away from the main group.

How about how much attributes are correlated to each other?

`matrix = np.triu(data.corr())`

fig, ax = plt.subplots(figsize=(15,10))

sns.heatmap(X_train.corr(), mask=matrix, ax=ax, cbar=True, annot=True, square=True)

plt.savefig('heatmap.png')

# 3. Data Preparation

Firstly, we shall look at the relationship of the selling price with the year of the vehicles.

from scipy import stats

from scipy.stats import norm, skewfig, ax = plt.subplots()

ax.scatter(x = data['year'], y = data['price'])

plt.ylabel('SalePrice', fontsize=13)

plt.xlabel('Year', fontsize=13)

plt.show()

Seem that we are having outliers. To do that, we choose to delete data that are lower than the 1st quantile and higher than the 3rd quantile. After the deletion, we have 324,723 rows of data remained.

Then, we want to look at the distribution of the price. We can plot this by using the seaborn.

`sns.distplot(data['price'], fit=norm)`

fig = plt.figure()

res = stats.probplot(data['price'], plot=plt)

From this, we can see that data does not have normal distribution, it contains peakedness (having a peak), have positive skewness (tail on the right side is longer), and not on the diagonal line.

To solve this problem, we can apply log function to the price.

data['price'] = np.log(data['price'])sns.distplot(data['price'], fit=norm)

fig = plt.figure()

res = stats.probplot(data['price'], plot=plt)

Now, it is time to handling other attributes. But before we get into that, we will add one more column and call it ‘age’, and drop the year column. With this, we will get the age of the car. We do this as we want to know how old are those second hand cars.

`data['age'] = 2021 - data['year']`

## Data Cleaning Step 1

Then, with the data, we need to create train and test set. We do this with the train_test_split from sklearn.model_selection

After splitting the data, the technique that we are going to use to fill the missing value of the data are

1. fill the missing value with “None”,

2. fill the missing value with 0.0,

3. fill the missing value with mode(),

4. fill the missing value with most occurred categories, and

5. replace ‘yes’ for rows with values and ‘no’ for rows without values.

For filling the missing value with “None”, we apply them to ‘manufacturer’, ‘model’, ‘condition’, ‘title_status’, ‘drive’, ‘size’, ‘type’ and ‘paint_color’.

For filling the missing value with 0.0, we apply them to ‘odometer’, ‘lat’, ‘long’ and ‘age’.

For filling the missing value with mode(), we apply them to ‘cylinders’, ‘title_status’, ‘transmission’ and ‘fuel’.

For ‘cylinders’ attributes, we filled the none value with ‘other’.

For ‘fuel’ attributes, we filled the non value with ‘gas’.

For ‘transmission’, we filled the value with ‘automatic’.

For ‘vin’, we use re to find rows with value, where we replace the value with ‘yes’, and we filled non value rows with ‘no’.

These cleaning needs to be apply to both X_train and X_test set.

import re

from sklearn.model_selection import train_test_split

train, test = train_test_split(data)#Split the data set

X_train = train.drop(['price'], axis='columns')

y_train = train['price']

X_test = test.drop(['price'], axis='columns')

y_test = test['price']#Fill the missing value with “None”

cols_for_none = ('manufacturer','model','condition','title_status','drive','size',

'type','paint_color')for c in cols_for_none:

X_train[c] = X_train[c].fillna("None")

X_test[c] = X_test[c].fillna("None")#Fill the missing value with 0.0

cols_for_zero = ('odometer','lat','long','age')for c in cols_for_zero:

X_train[c] = X_train[c].fillna(0.0)

X_test[c] = X_test[c].fillna(0.0)#Fill the missing value with mode()

cols_for_mode = ('cylinders','title_status','transmission','fuel')for c in cols_for_mode:

X_train[c] = X_train[c].fillna(X_train[c].mode())

X_test[c] = X_test[c].fillna(X_test[c].mode())#Fill the missing value with most occurred categories

X_train['cylinders'] = X_train['cylinders'].fillna("other")

X_train['fuel'] = X_train['fuel'].fillna('gas')

X_train['transmission'] = X_train['transmission'].fillna('automatic')X_test['cylinders'] = X_test['cylinders'].fillna("other")

X_test['fuel'] = X_test['fuel'].fillna('gas')

X_test['transmission'] = X_test['transmission'].fillna('automatic')#Replace ‘yes’ for rows with values and ‘no’ for rows without valuesX_train = X_train.replace({'vin':r'(\w*\S)'}, {'vin':"Yes"}, regex=True)

X_train['vin'] = X_train['vin'].fillna("No")X_test = X_test.replace({'vin':r'(\w*\S)'}, {'vin':"Yes"}, regex=True)

X_test['vin'] = X_test['vin'].fillna("No")

## Data Cleaning Step 2

Now, we filled all the missing data, but before we can train our model, we need to turn all categories data into numerical values. We can do this by using LabelEncoder from sklearn.preprocessing. Categories that we need to manage are ‘region’, ‘manufacturer’, ‘model’, ‘condition’, ‘fuel’, ‘title_status’, ‘title_status’, ‘transmission’, ‘vin’, ‘drive’, ‘size’, ‘type’, ‘paint_color’, ‘state’ and ‘cylinders’.

For ‘odometer’, it also does not have normal distribution, therefore we need to turn them into normal distribution as well.

from sklearn.preprocessing import LabelEncoder

le = LabelEncoder()#Listing all the categorial attributes

cols = ['region','manufacturer','model','condition','fuel','title_status','title_status','transmission','vin',

'drive','size','type','paint_color','state','cylinders']#Apply to both X_train and X_test data

for c in cols:

le.fit(list(X_train[c].values))

X_train[c] = le.transform(list(X_train[c].values))

for c in cols:

le.fit(list(X_test[c].values))

X_test[c] = le.transform(list(X_test[c].values))#Manage the distribution type of odometer data

log_value = ('odometer')for c in log_value:

X_train[c] = np.log1p(X_train[c])

X_test[c] = np.log1p(X_test[c])

Now, as all of our attributes are in numbers, we can look at how important each attribute is.

from sklearn.feature_selection import SelectKBest

from sklearn.feature_selection import f_regression#Show the important attributes in descending order

best_features = SelectKBest(score_func=f_regression, k=18)

top_features = best_features.fit(X_train,y_train)

scores = pd.DataFrame(top_features.scores_)

columns = pd.DataFrame(X_train.columns)featureScores = pd.concat([columns, scores], axis=1)

featureScores.columns = ['Features','Scores']

print(featureScores.nlargest(18, 'Scores'))

# 4. Model Comparison and Evaluation

Most of the work have been done. Now, we can run several regression models to compare each model accuracy. With each model, we apply 5 folds cross-validation.

With cross-validate, our 5 K-folds, it randomly splits data into 5 folds and train the model 5 times. Every fold, will be picking for evaluation at each of different time while the other 4 will be kept for training.

Let’s understand the model that we are going to select.

## Random Forest Regressor

This model trains multiple decision trees and the final result is the voting majority (for classification) or average voting (for regression). Each tree will draw random sample so this prevent overfitting and with large dataset, random forest seems to perform well.

## Gradient Boosting Regressor

The model prediction comes from the learning of the weak prediction from previous models. 1st tree prediction error *r1 *will be trained in the 2nd tree where it will get error *r2*. Then *r2* is used to train in 3rd tree, and so on until it reach *N* trees.

## Linear Regression

The most commonly seen regression model of all. The prediction (*y*) is estimated from the independent variables (*X1, X2, X3, … , Xn*). The error is the distance of *y* from the linear regression line.

## Extreme Gradient Boosting

Extreme Gradient Boosting (XGB) uses gradient boosting decision trees algorithms where its main objectives are the execution speed and the model performance. In recent years, many kaggle competition use XGB for their model.

Now, we lets look at the implementation and evaluation of each model.

from sklearn.linear_model import LinearRegression

from sklearn.ensemble import RandomForestRegressor, GradientBoostingRegressor

import xgboost as xgb

from sklearn.model_selection import cross_val_score

lr = LinearRegression()

rr = RandomForestRegressor()

gbr = GradientBoostingRegressor()

xgb = xgb.XGBRegressor()#Create function to displaying scores

def display_scores(scores):

print("Scores: ", scores)

print("Mean: ", scores.mean())

print("Standard Deviation: ", scores.std())#Training the Random Forest Regressor

print("Random Forest Regressor Scores")

scores = cross_val_score(rr, X_train, y_train, scoring='neg_mean_squared_error', cv=5)

random_forest_scores = np.sqrt(-scores)

display_scores(random_forest_scores)

print("\n")#Training the Gradient Boosting Regressor

print('Gradient Boosting Regressor Scores')

scores = cross_val_score(gbr, X_train, y_train, scoring='neg_mean_squared_error', cv=5)

gradient_boosting_regressor = np.sqrt(-scores)

display_scores(gradient_boosting_regressor)

print("\n")#Training the Linear Regression

print('Linear Regression Scores')

scores = cross_val_score(lr, X_train, y_train, scoring='neg_mean_squared_error', cv=5)

linear_regression = np.sqrt(-scores)

display_scores(linear_regression)

print("\n")#Training the Extreme Gradient Boosting

print("xGB Scores")

scores = cross_val_score(xgb, X_train, y_train, scoring='neg_mean_squared_error', cv=5)

xgb_regressor = np.sqrt(-scores)

display_scores(xgb_regressor)

From this, we can see that our random forest regressor receives the best score with mean of 0.3822 and standard deviation of 0.0027. Next best performer is the Gradient Boosting Regressor with the mean of 0.4471 and standard deviation of 0.0028. Third winner is the XGB with mean of 0.4473 and standard deviation of 0.0023.

# 5. Prediction

From our training model, Random Forest Regressor has the best performance with the lower mean error. With this, we will used them for the prediction.

#Do the prediction

rr.fit(X_train, y_train)

pred = rr.predict(X_test)#Convert the log value back to the original value

y_test = np.exp(y_test)

pred = np.exp(pred)#Calculate the error and accuracy

errors = abs(pred - y_test)

print('Average absolute error:', round(np.mean(errors), 2), 'degrees.')mape = 100*(errors / y_test)

accuracy = 100 - np.mean(mape)

print('Accuracy:', round(accuracy, 2), '%.')#Put the y_test and predict value into DataFrame to the ease of comparing the values

compare = pd.DataFrame()

compare['y_true'] = y_test

compare['y_predict'] = pred

From the prediction, we can see that its accuracy is 68.4% with the average error of 5105.99 degrees. The table compare the result of *actual y *and the *predicted y*

# Conclusion

With this, we cover lots of things from visualizing data, cleaning data, evaluating models, and do the prediction. The accuracy of the model might not be so high but we get to see the process of implement the regression prediction. To improve the prediction or model training, we can apply the adjustment in the model hyper parameter or select only most relevant attributes for our model.
