Configuring HA Kubernetes cluster on bare metal servers, monitoring, logs and usage examples. 3/3

Hi there and welcome back to the third part of the “Kubernetes on bare metal” tutorial,in this part I wanna pay attention to the cluster monitoring & collecting logs, also we’ll run some test application for utilising previously configured cluster components. After all we will implement some stress tests and will check stability of this cluster schema.

First and very popular tool that Kubernetes community can provide for getting some web UI and statistical data about your cluster, it’s Kubernetes Dashboard. In fact it still under developing, but even now it can provide some extra data for troubleshooting applications and managing the cluster resources also.

It’s a bit controversial theme, is it really need to have any WEB UI for the cluster management, or using a console kubectl tool is quite enough. Well, sometimes it may be useful and complementing each other.

Let’s deploy our own Kubernetes Dashboard and see then. Standard deployment will run this dashboard on localhost address only, so you’ll need to use kubectl proxy command to expose it, but it’ll be still available only on your kubectl control machine locally. This is not bad for the security reasons, but I like to have access to it outside cluster in my browser and I ready to take some risks (anyway it’s use ssl with strong token).

To use my way, you need to change a bit standard deployment file in service section. We’ll use our load balancer for exposing this dashboard on public address.

Login to the machine that have configured kubectl utility and create:

control# vi kube-dashboard.yaml
# Copyright 2017 The Kubernetes Authors.
#
# Licensed under the Apache License, Version 2.0 (the "License");
# you may not use this file except in compliance with the License.
# You may obtain a copy of the License at
#
# http://www.apache.org/licenses/LICENSE-2.0
#
# Unless required by applicable law or agreed to in writing, software
# distributed under the License is distributed on an "AS IS" BASIS,
# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
# See the License for the specific language governing permissions and
# limitations under the License.

# ------------------- Dashboard Secret ------------------- #

apiVersion: v1
kind: Secret
metadata:
labels:
k8s-app: kubernetes-dashboard
name: kubernetes-dashboard-certs
namespace: kube-system
type: Opaque

---
# ------------------- Dashboard Service Account ------------------- #

apiVersion: v1
kind: ServiceAccount
metadata:
labels:
k8s-app: kubernetes-dashboard
name: kubernetes-dashboard
namespace: kube-system

---
# ------------------- Dashboard Role & Role Binding ------------------- #

kind: Role
apiVersion: rbac.authorization.k8s.io/v1
metadata:
name: kubernetes-dashboard-minimal
namespace: kube-system
rules:
# Allow Dashboard to create 'kubernetes-dashboard-key-holder' secret.
- apiGroups: [""]
resources: ["secrets"]
verbs: ["create"]
# Allow Dashboard to create 'kubernetes-dashboard-settings' config map.
- apiGroups: [""]
resources: ["configmaps"]
verbs: ["create"]
# Allow Dashboard to get, update and delete Dashboard exclusive secrets.
- apiGroups: [""]
resources: ["secrets"]
resourceNames: ["kubernetes-dashboard-key-holder", "kubernetes-dashboard-certs"]
verbs: ["get", "update", "delete"]
# Allow Dashboard to get and update 'kubernetes-dashboard-settings' config map.
- apiGroups: [""]
resources: ["configmaps"]
resourceNames: ["kubernetes-dashboard-settings"]
verbs: ["get", "update"]
# Allow Dashboard to get metrics from heapster.
- apiGroups: [""]
resources: ["services"]
resourceNames: ["heapster"]
verbs: ["proxy"]
- apiGroups: [""]
resources: ["services/proxy"]
resourceNames: ["heapster", "http:heapster:", "https:heapster:"]
verbs: ["get"]

---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
name: kubernetes-dashboard-minimal
namespace: kube-system
roleRef:
apiGroup: rbac.authorization.k8s.io
kind: Role
name: kubernetes-dashboard-minimal
subjects:
- kind: ServiceAccount
name: kubernetes-dashboard
namespace: kube-system

---
# ------------------- Dashboard Deployment ------------------- #

kind: Deployment
apiVersion: apps/v1
metadata:
labels:
k8s-app: kubernetes-dashboard
name: kubernetes-dashboard
namespace: kube-system
spec:
replicas: 1
revisionHistoryLimit: 10
selector:
matchLabels:
k8s-app: kubernetes-dashboard
template:
metadata:
labels:
k8s-app: kubernetes-dashboard
spec:
containers:
- name: kubernetes-dashboard
image: k8s.gcr.io/kubernetes-dashboard-amd64:v1.10.1
ports:
- containerPort: 8443
protocol: TCP
args:
- --auto-generate-certificates
# Uncomment the following line to manually specify Kubernetes API server Host
# If not specified, Dashboard will attempt to auto discover the API server and connect
# to it. Uncomment only if the default does not work.
# - --apiserver-host=http://my-address:port
volumeMounts:
- name: kubernetes-dashboard-certs
mountPath: /certs
# Create on-disk volume to store exec logs
- mountPath: /tmp
name: tmp-volume
livenessProbe:
httpGet:
scheme: HTTPS
path: /
port: 8443
initialDelaySeconds: 30
timeoutSeconds: 30
volumes:
- name: kubernetes-dashboard-certs
secret:
secretName: kubernetes-dashboard-certs
- name: tmp-volume
emptyDir: {}
serviceAccountName: kubernetes-dashboard
# Comment the following tolerations if Dashboard must not be deployed on master
tolerations:
- key: node-role.kubernetes.io/master
effect: NoSchedule

---
# ------------------- Dashboard Service ------------------- #

kind: Service
apiVersion: v1
metadata:
labels:
k8s-app: kubernetes-dashboard
name: kubernetes-dashboard
namespace: kube-system
spec:
type: LoadBalancer
ports:
- port: 443
targetPort: 8443
selector:
k8s-app: kubernetes-dashboard

Then run it:

control# kubectl create -f kube-dashboard.yaml
control# kubectl get svc --namespace=kube-system
kubernetes-dashboard   LoadBalancer   10.96.164.141 192.168.0.240 443:31262/TCP   8h

Great, as you can see our LB added the 192.168.0.240 ip for this service, now you can try open https://192.168.0.240 to see the Kubernetes Dashboard.

We can use two ways to get access in to it, using theadmin.conf file from our master node, that we previously use for configuring the kubectl or by creating a specific Service Account for it ,with security token.

Lets create some admin user then:

control# vi kube-dashboard-admin.yaml
apiVersion: v1
kind: ServiceAccount
metadata:
name: admin-user
namespace: kube-system
---
apiVersion: rbac.authorization.k8s.io/v1beta1
kind: ClusterRoleBinding
metadata:
name: admin-user
roleRef:
apiGroup: rbac.authorization.k8s.io
kind: ClusterRole
name: cluster-admin
subjects:
- kind: ServiceAccount
name: admin-user
namespace: kube-system

control#
kubectl create -f kube-dashboard-admin.yaml
serviceaccount/admin-user created
clusterrolebinding.rbac.authorization.k8s.io/admin-user created

Then we need to get token we can use to log in:

control# kubectl -n kube-system describe secret $(kubectl -n kube-system get secret | grep admin-user | awk '{print $1}')

Name: admin-user-token-vfh66
Namespace: kube-system
Labels: <none>
Annotations: kubernetes.io/service-account.name: admin-user
kubernetes.io/service-account.uid: 3775471a-3620-11e9-9800-763fc8adcb06

Type: kubernetes.io/service-account-token

Data
====
ca.crt: 1025 bytes
namespace: 11 bytes
token: erJhbGciOiJSUzI1NiIsImtpZCI6IiJ9.eyJpc3MiOiJrdWJlcm5ldGVzL3NlcnZpY2VhY2NvdW50Iiwna3ViZXJuZXRlcy5pby9zZXJ2aWNlYWNjb3VudC9uYW1lc3BhY2UiOiJr
dWJlLXN5c3RlbSIsImt1YmVybmV0ZXMuaW8vc2VydmljZWFjY291bnQvc2VjcmV0Lm5hbWUiOiJhZG1pbi11c2VmLXRva2VuLXZmaDY2Iiwia3ViZXJuZXRlcy5pby9zZXJ2aWNlYWNjb3VudC9zZ
XJ2aWNlLWFjY291bnQubmFtZSI6ImFkbWluLXVzZXIiLCJrdWJlcm5ldGVzLmlvL3NlcnZpY2VhY2NvdW50L3NlcnZpY2UtYWNjb3VudC51aWQiOiIzNzc1NDcxYS0zNjIwLTExZTktOTgwMC03Nj
NmYzhhZGNiMDYiLCJzdWIiOiJzeXN0ZW06c2VydmljZWFjY291bnQ6a3ViZS1zeXN0ZW06YWRtaW4tdXNlciJ9.JICASwxAJHFX8mLoSikJU1tbij4Kq2pneqAt6QCcGUizFLeSqr2R5x339ZR8W4
9cIsbZ7hbhFXCATQcVuWnWXe2dgXP5KE8ZdW9uvq96rm_JvsZz0RZO03UFRf8Exsss6GLeRJ5uNJNCAr8No5pmRMJo-_4BKW4OFDFxvSDSS_ZJaLMqJ0LNpwH1Z09SfD8TNW7VZqax4zuTSMX_yVS
ts40nzh4-_IxDZ1i7imnNSYPQa_Oq9ieJ56Q-xuOiGu9C3Hs3NmhwV8MNAcniVEzoDyFmx4z9YYcFPCDIoerPfSJIMFIWXcNlUTPSMRA-KfjSb_KYAErVfNctwOVglgCISA

Now copy the token and paste it into Token field on login screen.

After you login, you can explore your cluster a bit more, I like this tool.

Next thing we can add for making our cluster monitoring more deep, it’s install heapster

Heapster enables Container Cluster Monitoring and Performance Analysis for Kubernetes (versions v1.0.6 and higher), and platforms which include it.

This tool can provide us console based cluster utilisation statistic, but also it’ll add more information about node and pods resources to the Kubernetes Dashboard too.

It a bit tricky to install it on bare metal cluster, an I was need to make some investigation about why it wasn’t work from “box” but I have found the decision.

So let’s go on and deploy this add-on:

control# vi heapster.yaml
apiVersion: v1
kind: ServiceAccount
metadata:
name: heapster
namespace: kube-system
---
apiVersion: extensions/v1beta1
kind: Deployment
metadata:
name: heapster
namespace: kube-system
spec:
replicas: 1
template:
metadata:
labels:
task: monitoring
k8s-app: heapster
spec:
serviceAccountName: heapster
containers:
- name: heapster
image: gcr.io/google_containers/heapster-amd64:v1.4.2
imagePullPolicy: IfNotPresent
command:
- /heapster
- --source=kubernetes.summary_api:''?useServiceAccount=true&kubeletHttps=true&kubeletPort=10250&insecure=true
---
apiVersion: v1
kind: Service
metadata:
labels:
task: monitoring
# For use as a Cluster add-on (https://github.com/kubernetes/kubernetes/tree/master/cluster/addons)
# If you are NOT using this as an addon, you should comment out this line.
kubernetes.io/cluster-service: 'true'
kubernetes.io/name: Heapster
name: heapster
namespace: kube-system
spec:
ports:
- port: 80
targetPort: 8082
selector:
k8s-app: heapster
---
kind: ClusterRoleBinding
apiVersion: rbac.authorization.k8s.io/v1beta1
metadata:
name: heapster
roleRef:
apiGroup: rbac.authorization.k8s.io
kind: ClusterRole
name: system:heapster
subjects:
- kind: ServiceAccount
name: heapster
namespace: kube-system

This is mostly standard deployment file from the Heapster community, but it differs a bit, for making it work on our cluster the “source=” string in heapster deployment has bin changed this way:

--source=kubernetes.summary_api:''?useServiceAccount=true&kubeletHttps=true&kubeletPort=10250&insecure=true

In this description you can find all this options. I have changed the kubelet port to 10250 and disable ssl certificate checking (there was some issue with it).

Also we need to add permissions, to get nodes statistic, in to the Heapster RBAC role, add this few stings to the end of the role:

control# kubectl edit clusterrole system:heapster
......
...
- apiGroups:
- ""
resources:
- nodes/stats
verbs:
- get

Finally your RBAC role must look like this:

# Please edit the object below. Lines beginning with a '#' will be ignored,
# and an empty file will abort the edit. If an error occurs while saving this file will be
# reopened with the relevant failures.
#
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
annotations:
rbac.authorization.kubernetes.io/autoupdate: "true"
creationTimestamp: "2019-02-22T18:58:32Z"
labels:
kubernetes.io/bootstrapping: rbac-defaults
name: system:heapster
resourceVersion: "6799431"
selfLink: /apis/rbac.authorization.k8s.io/v1/clusterroles/system%3Aheapster
uid: d99065b5-36d3-11e9-a7e6-763fc8adcb06
rules:
- apiGroups:
- ""
resources:
- events
- namespaces
- nodes
- pods
verbs:
- get
- list
- watch
- apiGroups:
- extensions
resources:
- deployments
verbs:
- get
- list
- watch
- apiGroups:
- ""
resources:
- nodes/stats
verbs:
- get

OK, now lets run a command to make sure our heapster deployment running successful.

control#  kubectl top node
NAME           CPU(cores)   CPU%   MEMORY(bytes)   MEMORY%
kube-master1 183m 9% 1161Mi 60%
kube-master2 235m 11% 1130Mi 59%
kube-worker1 189m 4% 1216Mi 41%
kube-worker2 218m 5% 1290Mi 44%
kube-worker3 181m 4% 1305Mi 44%

Good, if you got same output it’s mean that all was done right, now lets login back to our dashboard page and check new graphs that now available.

From now we can also see the real resources utilisation for the cluster nodes, pods and so on.

If this not enough, then you can improve your statistic a bit more and add the InfluxDB+Grafana. This will add ability to draw our own Grafana dashboards then.

We’ll use this InfluxDB+Grafana version of installation from the Heapster Git page, but with modification as usual. As we already have previously configured heapster deployment, the only things we need to do, it’s add Grafana and InfluxDB and change the existing heapster deployment then, to make it write metrics to Influx too.

OK, lets move on and create InfluxDB and Grafana deployments:

control# vi influxdb.yaml
apiVersion: extensions/v1beta1
kind: Deployment
metadata:
name: monitoring-influxdb
namespace: kube-system
spec:
replicas: 1
template:
metadata:
labels:
task: monitoring
k8s-app: influxdb
spec:
containers:
- name: influxdb
image: k8s.gcr.io/heapster-influxdb-amd64:v1.5.2
volumeMounts:
- mountPath: /data
name: influxdb-storage
volumes:
- name: influxdb-storage
emptyDir: {}
---
apiVersion: v1
kind: Service
metadata:
labels:
task: monitoring
# For use as a Cluster add-on (https://github.com/kubernetes/kubernetes/tree/master/cluster/addons)
# If you are NOT using this as an addon, you should comment out this line.
kubernetes.io/cluster-service: 'true'
kubernetes.io/name: monitoring-influxdb
name: monitoring-influxdb
namespace: kube-system
spec:
ports:
- port: 8086
targetPort: 8086
selector:
k8s-app: influxdb

Then Grafana, also don’t forget to change the service configuration for enabling MetaLB load balancer on it, to get external IP for Grafana service.

control# vi grafana.yaml
apiVersion: extensions/v1beta1
kind: Deployment
metadata:
name: monitoring-grafana
namespace: kube-system
spec:
replicas: 1
template:
metadata:
labels:
task: monitoring
k8s-app: grafana
spec:
containers:
- name: grafana
image: k8s.gcr.io/heapster-grafana-amd64:v5.0.4
ports:
- containerPort: 3000
protocol: TCP
volumeMounts:
- mountPath: /etc/ssl/certs
name: ca-certificates
readOnly: true
- mountPath: /var
name: grafana-storage
env:
- name: INFLUXDB_HOST
value: monitoring-influxdb
- name: GF_SERVER_HTTP_PORT
value: "3000"
# The following env variables are required to make Grafana accessible via
# the kubernetes api-server proxy. On production clusters, we recommend
# removing these env variables, setup auth for grafana, and expose the grafana
# service using a LoadBalancer or a public IP.
- name: GF_AUTH_BASIC_ENABLED
value: "false"
- name: GF_AUTH_ANONYMOUS_ENABLED
value: "true"
- name: GF_AUTH_ANONYMOUS_ORG_ROLE
value: Admin
- name: GF_SERVER_ROOT_URL
# If you're only using the API Server proxy, set this value instead:
# value: /api/v1/namespaces/kube-system/services/monitoring-grafana/proxy
value: /
volumes:
- name: ca-certificates
hostPath:
path: /etc/ssl/certs
- name: grafana-storage
emptyDir: {}
---
apiVersion: v1
kind: Service
metadata:
labels:
# For use as a Cluster add-on (https://github.com/kubernetes/kubernetes/tree/master/cluster/addons)
# If you are NOT using this as an addon, you should comment out this line.
kubernetes.io/cluster-service: 'true'
kubernetes.io/name: monitoring-grafana
name: monitoring-grafana
namespace: kube-system
spec:
# In a production setup, we recommend accessing Grafana through an external Loadbalancer
# or through a public IP.
# type: LoadBalancer
# You could also use NodePort to expose the service at a randomly-generated port
# type: NodePort
type: LoadBalancer
ports:
- port: 80
targetPort: 3000
selector:
k8s-app: grafana

And create them:

control# kubectl create -f influxdb.yaml
deployment.extensions/monitoring-influxdb created
service/monitoring-influxdb created
control# kubectl create -f grafana.yaml
deployment.extensions/monitoring-grafana created
service/monitoring-grafana created

Now it’s time to change a heapster deployment and add InfluxDB connection in to it, only one string we need to add for it:

- --sink=influxdb:http://monitoring-influxdb.kube-system.svc:8086

Edit heapster deployment:

control# kubectl get deployments --namespace=kube-system
NAME                   READY   UP-TO-DATE   AVAILABLE   AGE
coredns 2/2 2 2 49d
heapster 1/1 1 1 2d12h
kubernetes-dashboard 1/1 1 1 3d21h
monitoring-grafana 1/1 1 1 115s
monitoring-influxdb 1/1 1 1 2m18s
control# kubectl edit deployment heapster --namespace=kube-system
... beginning bla bla bla
spec:
containers:
- command:
- /heapster
- --source=kubernetes.summary_api:''?useServiceAccount=true&kubeletHttps=true&kubeletPort=10250&insecure=true
- --sink=influxdb:http://monitoring-influxdb.kube-system.svc:8086
image: gcr.io/google_containers/heapster-amd64:v1.4.2
imagePullPolicy: IfNotPresent
.... end

Now let’s find the Grafana service external IP and login inside it:

control# kubectl get svc --namespace=kube-system
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
..... some other services here
monitoring-grafana     LoadBalancer   10.98.111.200    192.168.0.241   80:32148/TCP    18m

Open http://192.168.0.241 in your browser, with admin/admin credentials at the first time:

My Grafana was empty after I have logged in, but fortunately we can get all needed dashboards from grafana.com, we need to import the number 3649 and 3646 dashboards. Choose the right data source when you’ll import them.

After this, you’ll be able to see Nodes and Pods resources utilisation and you can create own custom dashboards of course.

Well, that’s all about monitoring for now, next things we may need, it’s storing logs from our applications and cluster . There’s few ways how we can do it, all of them described in Kubernetes documentation. Based on my own experience I prefer to have an external installations of Elasticsearch & Kibana services and only logging agent will be running on every Kubernetes worker node. This will save our cluster from any overloads, due to the big amount of logs and other problems, also it’ll be possible to get logs even if our cluster will fully degrade.

Most popular log collecting stack for Kubernetes evangelists, it’s Elasticsearch, Fluentd and Kibana (EFK stack). In this example we’ll run Elasticsearch with Kibana on external node (you can use your existing ELK stack also) and will run a Fluentd inside our cluster as daemonset on each and every node, as log collecting agent.

I will pass out the section about creating the VM with Elasticsearch & Kibana installations, it’s a popular enough theme, so you can find a lot of documents about how to do it better, for example you can use mine article as well. Just remove the logstesh part of config from docker-compose.yml file and also remove 127.0.0.1 from the elasticsearch ports section.

After finishing you must have a working elasticsearch, that listened on VM-IP:9200 port, if you need any additional protection you can configure the login:pass or secure keys, between fluentd and elasticsearch. But I often just protecting it with iptables rules.

Only things we left to do now, it’s create some fluentd daemonset in Kubernetes and specify the outside elasticsearch node:port address in configuration.

We’ll use official Kubernetes Add-On yaml configs from there, with small modifications:

control# vi fluentd-es-ds.yaml
apiVersion: v1
kind: ServiceAccount
metadata:
name: fluentd-es
namespace: kube-system
labels:
k8s-app: fluentd-es
kubernetes.io/cluster-service: "true"
addonmanager.kubernetes.io/mode: Reconcile
---
kind: ClusterRole
apiVersion: rbac.authorization.k8s.io/v1
metadata:
name: fluentd-es
labels:
k8s-app: fluentd-es
kubernetes.io/cluster-service: "true"
addonmanager.kubernetes.io/mode: Reconcile
rules:
- apiGroups:
- ""
resources:
- "namespaces"
- "pods"
verbs:
- "get"
- "watch"
- "list"
---
kind: ClusterRoleBinding
apiVersion: rbac.authorization.k8s.io/v1
metadata:
name: fluentd-es
labels:
k8s-app: fluentd-es
kubernetes.io/cluster-service: "true"
addonmanager.kubernetes.io/mode: Reconcile
subjects:
- kind: ServiceAccount
name: fluentd-es
namespace: kube-system
apiGroup: ""
roleRef:
kind: ClusterRole
name: fluentd-es
apiGroup: ""
---
apiVersion: apps/v1
kind: DaemonSet
metadata:
name: fluentd-es-v2.4.0
namespace: kube-system
labels:
k8s-app: fluentd-es
version: v2.4.0
kubernetes.io/cluster-service: "true"
addonmanager.kubernetes.io/mode: Reconcile
spec:
selector:
matchLabels:
k8s-app: fluentd-es
version: v2.4.0
template:
metadata:
labels:
k8s-app: fluentd-es
kubernetes.io/cluster-service: "true"
version: v2.4.0
# This annotation ensures that fluentd does not get evicted if the node
# supports critical pod annotation based priority scheme.
# Note that this does not guarantee admission on the nodes (#40573).
annotations:
scheduler.alpha.kubernetes.io/critical-pod: ''
seccomp.security.alpha.kubernetes.io/pod: 'docker/default'
spec:
priorityClassName: system-node-critical
serviceAccountName: fluentd-es
containers:
- name: fluentd-es
image: k8s.gcr.io/fluentd-elasticsearch:v2.4.0
env:
- name: FLUENTD_ARGS
value: --no-supervisor -q
resources:
limits:
memory: 500Mi
requests:
cpu: 100m
memory: 200Mi
volumeMounts:
- name: varlog
mountPath: /var/log
- name: varlibdockercontainers
mountPath: /var/lib/docker/containers
readOnly: true
- name: config-volume
mountPath: /etc/fluent/config.d
terminationGracePeriodSeconds: 30
volumes:
- name: varlog
hostPath:
path: /var/log
- name: varlibdockercontainers
hostPath:
path: /var/lib/docker/containers
- name: config-volume
configMap:
name: fluentd-es-config-v0.2.0

Then we need to provide some configuration, for our fluentd:

control# vi fluentd-es-configmap.yaml
kind: ConfigMap
apiVersion: v1
metadata:
name: fluentd-es-config-v0.2.0
namespace: kube-system
labels:
addonmanager.kubernetes.io/mode: Reconcile
data:
system.conf: |-
<system>
root_dir /tmp/fluentd-buffers/
</system>
containers.input.conf: |-
<source>
@id fluentd-containers.log
@type tail
path /var/log/containers/*.log
pos_file /var/log/es-containers.log.pos
tag raw.kubernetes.*
read_from_head true
<parse>
@type multi_format
<pattern>
format json
time_key time
time_format %Y-%m-%dT%H:%M:%S.%NZ
</pattern>
<pattern>
format /^(?<time>.+) (?<stream>stdout|stderr) [^ ]* (?<log>.*)$/
time_format %Y-%m-%dT%H:%M:%S.%N%:z
</pattern>
</parse>
</source>
# Detect exceptions in the log output and forward them as one log entry.
<match raw.kubernetes.**>
@id raw.kubernetes
@type detect_exceptions
remove_tag_prefix raw
message log
stream stream
multiline_flush_interval 5
max_bytes 500000
max_lines 1000
</match>
# Concatenate multi-line logs
<filter **>
@id filter_concat
@type concat
key message
multiline_end_regexp /\n$/
separator ""
</filter>
# Enriches records with Kubernetes metadata
<filter kubernetes.**>
@id filter_kubernetes_metadata
@type kubernetes_metadata
</filter>
# Fixes json fields in Elasticsearch
<filter kubernetes.**>
@id filter_parser
@type parser
key_name log
reserve_data true
remove_key_name_field true
<parse>
@type multi_format
<pattern>
format json
</pattern>
<pattern>
format none
</pattern>
</parse>
</filter>
output.conf: |-
<match **>
@id elasticsearch
@type elasticsearch
@log_level info
type_name _doc
include_tag_key true
host 192.168.1.253
port 9200
logstash_format true
<buffer>
@type file
path /var/log/fluentd-buffers/kubernetes.system.buffer
flush_mode interval
retry_type exponential_backoff
flush_thread_count 2
flush_interval 5s
retry_forever
retry_max_interval 30
chunk_limit_size 2M
queue_limit_length 8
overflow_action block
</buffer>
</match>

This is very easy configuration, but it full enough for a quick start, it’ll collect a system and applications logs. If you’ll need something more complicated, you may read an official documentation about fluentd plugins and configs for Kubernetes.

Now let’s create a fluentd daemonset in our cluster:

control# kubectl create -f fluentd-es-ds.yaml
serviceaccount/fluentd-es created
clusterrole.rbac.authorization.k8s.io/fluentd-es created
clusterrolebinding.rbac.authorization.k8s.io/fluentd-es created
daemonset.apps/fluentd-es-v2.4.0 created
control# kubectl create -f fluentd-es-configmap.yaml
configmap/fluentd-es-config-v0.2.0 created

Make sure that all fluentd pods and other resources was started OK, and open Kibana then, in Kibana you need to find and add new index from fluentd. If you’ll find some, that’s mean everything was done right, if nope then check previous steps and recreate daemonset or edit configmap:

Great, now after we start getting some logs from our cluster, we can create any kind of dashboards we want. Well, of course it’s a very usual configuration so you may need to change it for your specific purposes. The main goal was to show the way how it can be done.

After all previously done steps, we got a really good looking, production ready Kubernetes cluster. So it’s time to deploy some test application in it and see how it’ll be.

We can take for this example my small Python/Flask Kubyk application ,that already have a Docker container so we can take it from public docker registry. Then we need to add an external database file for this app, we’ll use our configured GlusterFS storage for it.

First lets create a new pvc (persistent volume claim)volume for this app, we’ll store the SQLite database with users credentials in there. We can use a previously created storage class from part 2 of this tutorial.

control# mkdir kubyk && cd kubyk
control# vi kubyk-pvc.yaml
kind: PersistentVolumeClaim
apiVersion: v1
metadata:
name: kubyk
annotations:
volume.beta.kubernetes.io/storage-class: "slow"
spec:
accessModes:
- ReadWriteOnce
resources:
requests:
storage: 1Gi
control# kubectl create -f kubyk-pvc.yaml

After we have create a new PVC for our app we ready to deploy it.

control# vi kubyk-deploy.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
name: kubyk-deployment
spec:
selector:
matchLabels:
app: kubyk
replicas: 1
template:
metadata:
labels:
app: kubyk
spec:
containers:
- name: kubyk
image: ratibor78/kubyk
ports:
- containerPort: 80
volumeMounts:
- name: kubyk-db
mountPath: /kubyk/sqlite
volumes:
- name: kubyk-db
persistentVolumeClaim:
claimName: kubyk
control# vi kubyk-service.yaml
apiVersion: v1
kind: Service
metadata:
name: kubyk
spec:
type: LoadBalancer
selector:
app: kubyk
ports:
- port: 80
name: http

Now lets create deployment and service:

control# kubectl create -f kubyk-deploy.yaml
deployment.apps/kubyk-deployment created
control# kubectl create -f kubyk-service.yaml
service/kubyk created

Check the new assigned IP for service and pod status also:

control# kubectl get po
NAME                                READY   STATUS    RESTARTS AGE
glusterfs-2wxk7 1/1 Running 1 2d1h
glusterfs-5dtdj 1/1 Running 1 41d
glusterfs-zqxwt 1/1 Running 0 2d1h
heketi-b8c5f6554-f92rn 1/1 Running 0 8d
kubyk-deployment-75d5447d46-jrttp 1/1 Running 0 11s
control# kubectl get svc
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
... some text..
kubyk LoadBalancer 10.109.105.224 192.168.0.242 80:32384/TCP 10s

OK, it seems that we have successfully start our new application, if we’ll open http://192.168.0.242 IP in browser, we must see the login page of this app. We can use admin/admin credentials for login in, but if we try to login on this stage, we’ll get a error, as there is no database available yet.

There is a error log messages example from pod in Kubernetes dashboard:

To fix this situation, we need to copy the SQlite DB file, from my git repository into the previously created pvc volume. So application can start using this database then.

control# git pull https://github.com/ratibor78/kubyk.git
control# kubectl cp ./kubyk/sqlite/database.db kubyk-deployment-75d5447d46-jrttp:/kubyk/sqlite

We use the pod from application and kubectl cp command to copy this file into the volume.

Also we need grant a write access to this directory for nginx user, as in docker container, my application runs under nginx user by supervisord.

control# kubectl exec -ti kubyk-deployment-75d5447d46-jrttp -- chown -R nginx:nginx /kubyk/sqlite/

And let’s try to login one more time:

Great, now our app is working well, and we can scale this kubyk deployment up to 3 replica for example, for putting one copy of app on one worker node. As we have created pvc volume previously, all our pods with application replicas, will use same DB, and also service will balance traffic between replicas using round robin schema.

control# kubectl get deployments
NAME               READY   UP-TO-DATE   AVAILABLE   AGE
heketi 1/1 1 1 39d
kubyk-deployment 1/1 1 1 4h5m
control# kubectl scale deployments kubyk-deployment --replicas=3
deployment.extensions/kubyk-deployment scaled
control# kubectl get po
NAME                                READY   STATUS    RESTARTS   AGE
glusterfs-2wxk7 1/1 Running 1 2d5h
glusterfs-5dtdj 1/1 Running 21 41d
glusterfs-zqxwt 1/1 Running 0 2d5h
heketi-b8c5f6554-f92rn 1/1 Running 0 8d
kubyk-deployment-75d5447d46-bdnqx 1/1 Running 0 26s
kubyk-deployment-75d5447d46-jrttp 1/1 Running 0 4h7m
kubyk-deployment-75d5447d46-wz9xz 1/1 Running 0 26s

Now we got one replica of our app per one worker node, so if we’ll lose some of nodes, application will still continue working. Also we got an easy type of load balancing as I said previously. Not bad as for first time.

Lets create some new user in our application:

Any new requests will be processing by next pod in list, you can check this by looking in to the pods logs. For example new user will be created by application in one pod, then next pod will respond for next request and so on. As this app use same persistent volume for storing DB even if all of the replicas will disappear, all data will be in safe.

In big and complicated applications we’ll need not only dedicated volume for the DB, but also different volumes for placing static content and more else things in them.

Well, it seems that we almost finished with this part of tutorial, there is a lot of things I can add, because the Kubernetes theme is big and dynamically growing, but I’ll stop for now. The main goal for this articles cycle was showing the way of creating own Kubernetes cluster and I hope this was useful enough for you.

P.S

Stability and stress tests, of course.

Cluster schema that we used in this example may continue working without 2 workers nodes, 1 master and 1 etcd node. You can shutdown them and see that our test app still working.

When I wrote this tutorials, I have preparing same cluster for the production, in fact almost same scheme. At one day, when the cluster was created and some part of application was deployed in it, there was a big power supply issue in the DC and totally all of cluster servers was shut downed, like in scary movies for sysadmins. Some of servers was down for a long time and some got a file system errors after it. But when I started them all again, I was very surprising when Kubernetes cluster fully recovered. All GlusterFS volumes, all deployments has started. It shows a big potential for this technology as for me.

Goodbye and hope to meet you again.
