WAX Technical How To #13

In WAX Technical How To #5 and #6 the topic of building, configuring and optimising a reliable WAX Load Balancer was explored in detail. In these articles HAProxy was used due to us at EOSphere being quite familiar with the platform's capability and feature-set.

Recently in a conversation with Anders|Anyobservation|Björk creator of Anyobservation | Crypto Fun Stuff he advised that many new community members were attempting to run all of their public services on a single node, not being aware that this can have an impact on the speed and reliability of their offering.

This #13 WAX Technical How To Edition will discuss the process and configuration of separating specific public API queries between nodes using HAProxy.

How to route specific API queries between nodes

Before routing API queries are discussed it should be mentioned that easily one of the quickest wins to improve the performance/speed of WAX software nodeos public services, is to provide separate nodes specifically for advertised public peers (P2P). 100+ Peers on a node can take up more than 50% of a nodeos process leaving less for API queries.

nodeos which is the core service daemon of WAX software, runs on every WAX Protocol Network node and is unfortunately primarily single threaded. This means that the more instances of the nodeos service available for public API queries the more performant and load balanced an API service offering can be. Also some WAX public services are offered using other software and have their own unique technical requirements such as a Hyperion, Atomic API or even a Website.

In this example HAProxy will be used to create policies allowing a public API service to be distributed between multiple nodes based on the requested query. Be sure to review WAX Technical How To #5 for details on how to build and configure HAProxy in it’s entirety.

Configuration

All HAProxy configuration is found in haproxy.cfg

In this example the goal is to:

• Configure the HAProxy frontend to recognise traffic based on URL (frontend is a public IP and backend is a private LAN)
• Configure the frontend to route traffic to the appropriate backend servers based on specific query
• Configure backend servers, load balance algorithm and thresholds

Follow the example below to configure each section in the new haproxy.cfg :

> sudo nano /etc/haproxy/haproxy.cfg

frontend

Configure an access-list called wax_acl to recognise requests for your URL, in this case wax.eosphere.io . Doing this will allow you to scale this loadbalancer to support multiple URL’s and networks.

frontend http-in
acl wax_acl hdr(host) -i wax.eosphere.io

Bind the above access-list to a backend server group as well as specify where each specific query should be routed. The configuration example below does the following:

• Normal v1 API queries are sent to the wax_api_servers backend
• Normal v1 API block queries are sent to the wax_api_blocks_servers backend, these servers have the full block.log
• History v1 and v2 queries are sent to the wax_hyperion_servers backend, which is a Hyperion cluster
• Hyperion Swagger and Block Explorer web portals are sent to the wax_hyperion_servers_web backend
• Atomic API queries are sent to the wax_atomic_api_serversbackend, which is a atomic eosio-contract-api server

frontend http-in
use_backend wax_hyperion_servers_web if wax_acl { path_beg /v2/docs }
use_backend wax_hyperion_servers_web if wax_acl { path_beg /v2/explore }
use_backend wax_hyperion_servers if wax_acl { path_beg /v2 }
use_backend wax_hyperion_servers if wax_acl { path_beg /v1/history }
use_backend wax_hyperion_servers if wax_acl { path_beg /socket.io }
use_backend wax_api_block_servers if wax_acl { path_beg /v1/chain/get_block }
use_backend wax_api_servers if wax_acl { path_beg /v1/chain }
use_backend wax_api_servers if wax_acl { path_beg /v1/node }
use_backend wax_atomic_api_servers if wax_acl { path_beg /health }
use_backend wax_atomic_api_servers if wax_acl { path_beg /atomicassets }
use_backend wax_atomic_api_servers if wax_acl { path_beg /atomictools }
use_backend wax_atomic_api_servers if wax_acl { path_beg /atomicmarket }

It is important to be aware that the frontend rules need to be ordered from most specific to least specific, for example path_beg / at the top of the list will superseded all the rules below it.

backend

Configure the backend server groups to match your infrastructure and apply specific policies for each server group.

The backend provides and excellent place to apply specific thresholds to mitigate abuse as discussed in WAX Technical How To #6 , along with specific query routing it should be clear that HAProxy can be leveraged for excellent policy granularity.

The configuration below provides example servers and policy to match the above configuration.

backend wax_hyperion_servers_web
    balance roundrobin
    default-server check maxconn 1000
    server wax-hyperion-3 <PRIVATE LAN IP>:7000 cookie server1
backend wax_hyperion_servers
    balance roundrobin
    default-server check maxconn 500
    server wax-hyperion-1 <PRIVATE LAN IP>:7000 cookie server1
    server wax-hyperion-2 <PRIVATE LAN IP>:7000 cookie server2
backend wax_api_block_servers
    balance roundrobin
    default-server check maxconn 3000
    server wax-pn-4 <PRIVATE LAN IP>:8888 cookie server1
backend wax_api_servers
    balance roundrobin
    default-server check maxconn 3000
    server wax-pn-1 <PRIVATE LAN IP>:8888 cookie server1
    server wax-pn-2 <PRIVATE LAN IP>:8888 cookie server2
    server wax-pn-3 <PRIVATE LAN IP>:8888 cookie server3
backend wax_atomic_api_servers
    balance leastconn
    default-server check maxconn 800
    server wax-atomic-1 <PRIVATE LAN IP>:9000 cookie server1
    server wax-atomic-2 <PRIVATE LAN IP>:9000 cookie server2

Please note, this article isn’t a guide on how to set up your specific infrastructure or granular query routing policy. However knowing how HAProxy can be configured to optimise your public service offering hopefully you now feel more confidant in scaling API’s on an extremally demanding and busy network such as the WAX Mainnet.
