Toyota and CARMERA Team up to Build High Definition Maps for Automated Vehicles Using Camera Data

Toyota Research Institute-Advanced Development, Inc. (“TRI-AD”) and CARMERA are joining forces to develop camera-based automation of HD maps for urban and surface roads. This is the first step towards realizing TRI-AD’s open software platform concept known as Automated Mapping Platform (“AMP”) to support the scalability of highly automated driving, by combining data gathered from vehicles of participating companies to generate HD maps.

CARMERA
CARMERA
Feb 28, 2019 · 3 min read

Automated driving requires highly reliable road information based on HD map data. While the creation of highway HD maps is underway, this coverage represents less than 1 percent (*1) of the worldwide road network. The next challenge is to create and maintain maps for urban areas and local roads that go beyond the highway road network.

In this proof of concept, the two companies will place cameras in Toyota test vehicles to collect data over several months from areas of downtown Tokyo. The cameras installed in the test vehicles use Toyota Safety Sense(*2) (“TSS”) components that Toyota installs on its vehicles globally. Images and other data gathered from TSS will be processed on CARMERA’s real-time platform to automatically generate HD map data. In addition, by placing commercially available “dashcam” drive recorders(*3) in Toyota test vehicles, the project will demonstrate automated map generation from a broader range of sources that do not have TSS. This draws upon CARMERA’s millions of miles of driving video collected, structured and enriched through safety monitoring partnerships with professional fleets in other complex environments like New York City.

CARMERA feature detection from Toyota Safety Sense cameras in downtown Tokyo
TRI-AD / CARMERA mapmaking from vehicle cameras in downtown Tokyo

By combining maps automatically generated via the techniques employed in this project with digital maps available today, it will be possible to provide even more reliable road information to automated vehicles in the future. And by generating HD maps based on data acquired from commercially available vehicles around the world, automated driving can be enabled on all roads.

Mandali Khalesi, Vice President Automated Driving at TRI-AD, said:

“Currently automated driving map development relies on highly expensive specialized mapping vehicles deployed in limited numbers, and a lengthy manual process for reliable HD map creation. We’re excited to partner with CARMERA to automate HD map generation and help enable automated driving mobility for all.”

“CARMERA was founded to deploy next-generation street intelligence at low cost, high speed and automotive-grade reliability, in order to democratize autonomous mobility at global scale. We’re excited to collaborate with TRI-AD in putting the flexibility and modularity of our platform to work to build HD maps, beginning with one of the largest and most dynamic urban environments in the world.”

1. Assuming HD maps available for the entire highway road network for the US, China, Germany and Japan (0.23M km), this represents less than 1% of the global road network (39.5M km).

2. Also installed as Lexus Safety System (LSS) for Lexus vehicles.

3. Refers to Denso-made data-transmission driving recorder.
