Disassemble Elixir code

And check if Erlang dead code elimination works

HOW DO YOU DO IT??? MINDBLOWING!

Sometime to understand what happens under the hood of the Elixir program and how it is optimized you need go really low-level. Here is two ways to check what code was generated.

During compilation Elixir is translated first to Core Erlang and then by Erlang compiler — to BEAM code.

Test source code

Here is source code of module I’ll use for testing. I was interested if dead code inside if will be removed from compiled version.

defmodule Test do
  @flag1 false
  def init() do
    IO.puts "Execute always"
    if @flag1 do
      IO.puts "Execute in feature flag"
    end
    42
  end
end

Retrieve Core Erlang / IR / Intermediate Representation

Run iex in your project directory and enter following commands:

f = './_build/dev/lib/test/ebin/Elixir.Test.beam'
result = :beam_lib.chunks(f,[:abstract_code])
{:ok,{_,[{:abstract_code,{_,ac}}]}} = result
IO.puts :erl_prettypr.format(:erl_syntax.form_list(ac))

Note that I use charlist '' and not string "" because this code uses Erlang libraries which are designed around charlists.

This will produce pretty much readable Erlang code.

-file("lib/test.ex", 1).
-module('Elixir.Test').
-compile(no_auto_import).
-export(['__info__'/1, init/0]).
-spec '__info__'(attributes | compile | functions |
                 macros | md5 | module) -> atom() |
                                           [{atom(), any()} |
                                            {atom(), byte(), integer()}].
'__info__'(module) -> 'Elixir.Test';
'__info__'(functions) -> [{init, 0}];
'__info__'(macros) -> [];
'__info__'(attributes) ->
    erlang:get_module_info('Elixir.Test', attributes);
'__info__'(compile) ->
    erlang:get_module_info('Elixir.Test', compile);
'__info__'(md5) ->
    erlang:get_module_info('Elixir.Test', md5).
init() ->
    'Elixir.IO':puts(<<"Execute always">>),
    case false of
      false -> nil;
      true -> 'Elixir.IO':puts(<<"Execute in feature flag">>)
    end,
    42.

Surprise! For some reason there is case included with dead code inside.

Then I tried to look into lower level disassembly to determine what is happening actually.

Retrieve BEAM disassembly

Now let’s look inside compiler byte code and see what’s happening there.

f = ‘./_build/dev/lib/test/ebin/Elixir.Test.beam’
{:ok, beam} = File.read(f)
IO.inspect :beam_disasm.file(beam), pretty: true

Turns out Erlang compiler is quite smart and takes care of this code. BEAM code disassembly looks quite different from Erlang code, but you can make sense of it too :) Here is relevant part for function init

{
      :function,
      :init,
      0,
      7,
      [
        {:line, 1},
        {:label, 6},
        {:func_info, {:atom, Test}, {:atom, :init}, 0},
        {:label, 7},
        {:allocate, 0, 0},
        {:move, {:literal, "Execute always"}, {:x, 0}},
        {:line, 2},
        {:call_ext, 1, {:extfunc, IO, :puts, 1}},
        {:move, {:integer, 42}, {:x, 0}},
        {:deallocate, 0},
        :return
      ]
    }

You can see that there is no mention of case as it was removed.
