How to send AWS CloudWatch Alarms to Slack

Alex Barashkov
Oct 18, 2018 · 5 min read
Image for post
Image for post

Alarm and monitoring systems are a key part of mature products and applications. If you worry about your customers, it’s better to be notified when something goes wrong then be in the dark. If you host your infrastructure on AWS, the only one way to get the full metrics of your used services is to use CloudWatch. AWS CloudWatch doesn’t only give you access to metrics, however, it also creates alarms for specific cases. But, if you worked with AWS before you no doubt noticed that the interface and certain functions are a far cry from “user friendly,” which means that sending a notification with alarms to Slack not a trivial task.

This article reveals the secrets you should know to set up the alarms you need in five minutes. For those of you who would like to see all in action, please watch our video tutorial.

There are a few steps we will need to go through to make this happen:

  • Create an AWS Access Key and Secret
  • Create a Role
  • Deploy the Lambda function
  • Create an SNS topic and subscription
  • Create a Cloudwatch Alarm

1. Create AWS Access Key and Secret

If you already have your AWS Access Key and Secret, you can skip this step. Otherwise, follow this link. Choose your user, then go to the Security Credentials tab and click Create Access Key.

Image for post
Image for post

Copy the AWS Access Key and Secret; we will use them during configuring deployment of Lambda Function.

Create a Role

The Role will be used by your Lambda function and requires permission to do certain things.
Follow this link then click Create Role.

Image for post
Image for post

Chose Lambda from the list.

Find AWSLambdaBasicExecutionRole and select it.

Image for post
Image for post

Finally, type a role name, such as “cloudwatch-to-slack-role,” click on the newly created role in the list and copy the ARN name. We will use it in step 3 during deployment of the Lambda function.

Image for post
Image for post
Image for post
Image for post

3. Deploy the Lambda function

To deploy the AWS Lambda function, you need to clone the repository and have Node.js installed on your local machine. Especially for that guide, we contributed significantly in the repository to get a better configuration process.

git clone git@github.com:assertible/lambda-cloudwatch-slack.git
cd lambda-cloudwatch-slack
cp .env.example .env

Open your .env file and fill in the environment variables.

UNENCRYPTED_HOOK_URL
That variable you should fill with the Slack Incoming Webhook; create a new one for CloudWatch on that page for your organization

Image for post
Image for post

Follow the practice of using one hook for one specific service. Once you create a webhook, choose a channel, then post notifications, create a username(the title for messages) and, of course, add a nice picture. Download the Cloudwatch logo from the link here

Image for post
Image for post

AWS_FUNCTION_NAME
The name of your function which will be declared in your AWS Lambda function page. Let’s call it “cloudwatch-to-slack.”

AWS_REGION=eu-west-1
Chose the region of the Lambda function.

AWS_ROLE=”arn:aws:iam::123456789123:role/lambda_exec_role”
Copy the arn id from the second step here.

AWS_ACCESS_KEY_ID
AWS_SECRET_ACCESS_KEY
Fill in the AWS Access Key and Secret with your keys from the first step.

Now we’re ready to deploy; simply execute the following command in your terminal from the folder with the repository we cloned:

npm install
npm run deploy

If everything went well, you will be able to find your fresh installed function on the Lambda page in AWS.

Image for post
Image for post

4. Create an SNS topic and subscription

Browse in AWS to the Simple Notification Service. Ironically, this service is anything but simple, especially the terminology they use and steps you have to go through.

Go to Topics and click Create New Topic. I chose the name “cloudwatch-alarms” for the notification that will be sent.

Image for post
Image for post
Image for post
Image for post

Open the created topic and create a subscription.

Image for post
Image for post

Select AWS Lambda as your Protocol and pick the endpoint with the name of your function.

Image for post
Image for post

That’s it; now we are ready to create an alarm.

5. Create Cloudwatch Alarm

Navigate through Cloudwatch to your AWS account and click Create Alarm.

Image for post
Image for post

Chose the metric you would like to monitor, define the alarm configuration and select your SNS topic name in the Send Notification To section.

Image for post
Image for post

I recommend that you specifically define conditions that will immediately throw alarms for the purposes of testing your function. If everything is configured properly, you will see the message in your Slack channel.

Image for post
Image for post

I hope this guide helps you save time and set up alarms for your current or future projects.

Additional notes:
By default, AWS Lambda has blueprints that allow you to do different things with a simple configuration and, in those blueprints, you may even find a CloudWatch-to-Slack function. Unfortunately, this send a very poor, unstructured data to the channel.

Tap the 👏 button if you found this article useful!

Any questions or Feedback? Connect via Pixel Point
