Upgrading PostgreSQL on AWS RDS with minimum or zero downtime

In this article, I will share all the details regarding the upgrade of our databases on Amazon Cloud as well as unveil the reason why we ended up using Bucardo for asynchronous multi-master replication and why we have eventually upgraded our production database with downtime.

My name is Amet Umerov and I’m a DevOps Engineer at Preply.com.

Contents

• Introduction
• Multi-master replication
• WTF is Bucardo
• Upgrading stage DB without downtime using Bucardo
• Production issues
• Upgrading production DB with downtime
• Key takeaways

Introduction

Our entire infrastructure is run by Amazon Cloud. We deploy our apps via ElasticBeanstalk and store our data in PostgreSQL RDS.

Simplified application architecture

We use Amazon Redshift for storing analytics data (DWH). We needed to upgrade our stage and production PostgreSQL DB from 9.4 to 9.5 in order to make cross-platform queries between our PostgreSQL DB and Redshift with the help of dblink.

Amazon allows bumping only one major version of PostgreSQL. So you cannot simply upgrade it from 9.4 to 9.6 but only to 9.5 first and then repeat this procedure again from 9.5 to 9.6.

(UPD: AWS already supports multi-major version upgrade).

Also, you cannot get access to PostgreSQL superuser, because Amazon only allows creating a user with RDS_SUPERUSER role with some limits.

You should have a login and password for RDS_SUPERUSER for allowing replica or use of non-default parameters group for changing some parameters. In case you lost or forgot your master password you could restore it without downtime. But if you want to change your parameters group — be ready to have a downtime.

Our main goal was to upgrade the database with zero downtime, and we could only achieve that by using multi-master replication of the production database.

Multi-master replication

Unlike the well-known master-slave replication, multi-master means that your app has the ability to use the same tables on different masters with all the changes being made automatically between all masters in this replication group.

Multisource multi-master replication

Setting up a reliable multi-master replication in PostgreSQL is undoubtedly challenging. Relational DBMSs aren’t designed for this purpose at all.
In the case of a highload project, conflicts will inevitably occur and will have to be tracked and resolved somehow. In case they have launched automatically, conflict resolution systems can only overwrite data which will lead to their loss.

Frankly speaking, there are a lot of problems, and it’s better to use document-oriented DBMS with such tasks. But if you want to configure such replication for PostgreSQL, it’s desirable to have a database where:

• unlinked tables or limited presence of such links
• no foreign keys
• randomly not sequentially generated IDs
• preferably no triggers

Thankfully, we are not alone in this world and there are some tools that can help us solve these problems.
Here is a full list of them with a comparison matrix. After doing a bit of research, several instruments have been identified, among which:

• BDR
• PgCluster
• rubygrep
• Bucardo

Since our PostgreSQL server is not recompilable, it’s not really possible to use BDR and PgCluster because they require additional plugins. rubygrep, on the other hand, seems to be a dead project without any successful usage proof.

For the above-stated reasons, Bucardo ended up being the most attractive option and in the next paragraph, I will illustrate why.

WTF is Bucardo

Bucardo is an asynchronous PostgreSQL replication system, that allows both multi-master and multi-slave operations. What is more important, Bucardo is a free open source software.

We chose Bucardo because of its stability, ease and good reviews. In fact, Bucardo is a perl-script which adds triggers to replicated tables for INSERT, UPDATE, DELETE operations and duplicate these operations to other servers through multi-master replication.

How Bucardo works

In order for Bucardo to work we should set:

• databases which participate in replication
• tables
• table and database groups

If a new table is added into one of the masters in replica we should also add it to Bucardo manually, as it belongs to table schemas.

Upgrading stage DB without downtime using Bucardo

So, we want to upgrade our PostgreSQL from 9.4 to 9.5 without downtime.
Here is a short playbook for it:

• take a snapshot of existing RDS instance
• create new master based on this snapshot
• upgrade new master using AWS RDS
• create multi-master group, add both master servers to replica
• switch the app from old master to new master

Let’s go!

Prerequisites

Get master’s endpoint and set credentials for DB:

export AWS_DEFAULT_REGION=eu-west-1
export MASTER_NAME=pgmaster
export PGUSERNAME=rds_superuser
export PGPASSWORD=rds_superuser_password
export PGENDPOINT=$(aws rds describe-db-instances --db-instance-identifier ${MASTER_NAME} --query 'DBInstances[*].Endpoint.[Address]' --output text)

We need to have superuser credentials for this DB. Remember it? We also recommend not to use the default parameters group in RDS, create it before creating any new RDS instance.

Create a snapshot from DB instance:

aws rds create-db-snapshot \
--db-snapshot-identifier ${MASTER_NAME}-snapshot \
--db-instance-identifier ${MASTER_NAME}

Wait for some time (depends on DB size) and check the snapshot status:

aws rds describe-db-snapshots --db-snapshot-identifier ${MASTER_NAME}-snapshot --query 'DBSnapshots[*].[Status]' --output text
available

Create a new master, based on this snapshot:

aws rds restore-db-instance-from-db-snapshot \
--db-instance-identifier ${MASTER_NAME}-2 \
--db-snapshot-identifier ${MASTER_NAME}-snapshot

Wait for a couple of minutes and check new master status:

aws rds describe-db-instances --db-instance-identifier ${MASTER_NAME}-2 --query 'DBInstances[*].[DBInstanceStatus]' --output text
available
PGENDPOINT_2=$(aws rds describe-db-instances --db-instance-identifier ${MASTER_NAME}-2 --query 'DBInstances[*].Endpoint.[Address]' --output text)
psql -h ${PGENDPOINT_2} -U ${PGUSERNAME} postgres -c "SHOW server_version;" -t
9.4.15

At this time we have two instances: pgmaster and pgmaster-2. They are both PostgreSQL version 9.4 . Let’s upgrade our new master to 9.5 version.

Go to AWS Management Console and edit pgmaster-2 configuration:

• set same subnet group and security group as pgmaster
• set PostgreSQL version 9.5.13-R1
• set new parameters group (if you created it earlier)

Save configuration and apply changes immediately.

Wait for some minutes (or hours) and check new master’s version:

psql -h ${PGENDPOINT_2} -U ${PGUSERNAME} postgres -c "SHOW server_version;" -t
9.5.13

Multi-master replication

For creating multi-master replication we need to have EC2 instance with Bucardo. Create a new instance based on Ubuntu 16.04:

• use the same region as RDS instances
• use same VPC, subnet group, and security group as RDS
• tag: Name — bucardo-stage
• create a new SSH key pair bucardo-stage

Connect to instance and install Bucardo:

ssh ubuntu@bucardo-stage-ip -i bucardo-stage.pem

apt update && apt install bucardo postgresql-plperl-9.5 -y
export PGPASSWORD=yourSecurePasswordForPostgres
# Enable Bucardo and create workdir for it
sed -i 's/ENABLED=0/ENABLED=1/' /etc/default/bucardo
mkdir /var/run/bucardo

# Setup superuser password for local DB
sudo -u postgres psql postgres
postgres=# \password postgres

# Create DB and user for Bucardo
psql -U postgres postgres << EOF
CREATE USER bucardo WITH LOGIN SUPERUSER ENCRYPTED PASSWORD 'bucardoPassword';
CREATE DATABASE bucardo;
EOF
bucardo install

Connect from bucardo-stage instance to RDS:

export PGENDPOINT=pgmaster.eu-west-1.rds.amazonaws.com
export PGENDPOINT_2=pgmaster-2.eu-west-1.rds.amazonaws.com
export PGUSERNAME=postgres
export PGPASSWORD=yourSecurePasswordForPostgres

Prepare pgmaster and pgmaster-2 servers for replication:

psql -h ${PGENDPOINT} -U ${PGUSERNAME} postgres -c "CREATE EXTENSION plperl;"
psql -h ${PGENDPOINT_2} -U ${PGUSERNAME} postgres -c "CREATE EXTENSION plperl;"

Add servers to replication group:

export DATABASE=database
# Grant user postgres for tables and sequences
psql -h ${PGENDPOINT} -U ${PGUSERNAME} ${DATABASE} -W << EOF
GRANT ALL PRIVILEGES ON ALL TABLES IN SCHEMA public TO postgres;
GRANT ALL PRIVILEGES ON ALL SEQUENCES IN SCHEMA public TO postgres;
EOF
psql -h ${PGENDPOINT_2} -U ${PGUSERNAME} ${DATABASE} -W << EOF
GRANT ALL PRIVILEGES ON ALL SEQUENCES IN SCHEMA public TO postgres;
GRANT ALL PRIVILEGES ON ALL TABLES IN SCHEMA public TO postgres;
EOF
# Add both masters to Bucardo
bucardo add db source_db dbhost=${PGENDPOINT} dbport=5432 dbname=${DATABASE} dbuser=${PGUSERNAME} dbpass=${PGPASSWORD}
bucardo add db dest_db dbhost=${PGENDPOINT_2} dbport=5432 dbname=${DATABASE} dbuser=${PGUSERNAME} dbpass=${PGPASSWORD}

bucardo list database

Add all tables and sequences into the replication group:

bucardo add table all --db=source_db --herd=sample_herd
bucardo add sequence all --db=source_db --herd=sample_herd

Create a multi-master replication group:

bucardo add dbgroup mydb_servers_group
bucardo add dbgroup mydb_servers_group source_db:source
bucardo add dbgroup mydb_servers_group dest_db:source
bucardo add sync mydb_sync herd=sample_herd dbs=mydb_servers_group
bucardo list sync

We have two source databases here, it means that we have a multi-master replication, not a master-slave.

In a new terminal tab, run the script for checking DB downtime:

cat << EOF > checkdb.sh
#!/bin/bash

export PGPASSWORD=yourSecurePasswordForPostgres
export PGCONNECT_TIMEOUT=5
export DATABASE=database
export PGUSERNAME=postgres

while true; do
    date
    psql -h pgmaster-2.eu-west-1.rds.amazonaws.com \
    -U ${PGUSERNAME} -d ${DATABASE} -t \
    -c 'SELECT * FROM table LIMIT 1;'
    sleep 2
done
EOF

bash checkdb.sh

This script will be checking the connection to your new master with a simple query every 2 seconds.

Start Bucardo:

bucardo start
bucardo status

Replication testing

How it will be tested? We will run INSERT, UPDATE, DELETE operations on both masters and check how replica works.

INSERT

Write to source master, check on destination master:

psql -h ${PGENDPOINT} -U ${PGUSERNAME} ${DATABASE} \
-c "INSERT INTO table (id, name) VALUES (1, 'one');"

psql -h ${PGENDPOINT_2} -U ${PGUSERNAME} ${DATABASE} \
-c "SELECT * FROM table WHERE id=1;"

Write to the destination, check on source:

psql -h ${PGENDPOINT_2} -U ${PGUSERNAME} ${DATABASE} \
-c "INSERT INTO table (id, name) VALUES (2, 'two');"

psql -h ${PGENDPOINT} -U ${PGUSERNAME} ${DATABASE} \
-c "SELECT * FROM table WHERE id=2;"

UPDATE

Update on the source, check on destination:

psql -h ${PGENDPOINT} -U ${PGUSERNAME} ${DATABASE} -c "UPDATE table SET name='one_one' WHERE id=1;"
psql -h ${PGENDPOINT_2} -p 5432 -U ${PGUSERNAME} ${DATABASE} -c "SELECT * FROM table WHERE id=1;"

Update on the destination, check on source:

psql -h ${PGENDPOINT_2} -U ${PGUSERNAME} ${DATABASE} -c "UPDATE table SET name='two_two' WHERE id=2;"
psql -h ${PGENDPOINT} -U ${PGUSERNAME} ${DATABASE} -c "SELECT * FROM table WHERE id=2;"

DELETE

Delete on the source, check on destination:

psql -h ${PGENDPOINT} -U ${PGUSERNAME} ${DATABASE} -c "DELETE FROM table WHERE id=1;"
psql -h ${PGENDPOINT_2} -U ${PGUSERNAME} ${DATABASE} -c "SELECT * FROM table WHERE id=1;"

Delete on the destination, check on source:

psql -h ${PGENDPOINT_2} -U ${PGUSERNAME} ${DATABASE} -c "DELETE FROM table WHERE id=2;"
psql -h ${PGENDPOINT} -U ${PGUSERNAME} ${DATABASE} -c "SELECT * FROM table WHERE id=2;"

Well, we tested our multi-master replication and it looks good.

Useful Bucardo commands

Let’s check Bucardo replication status:

bucardo delta source_db
bucardo delta dest_db
bucardo status mydb_sync

We also could check lag between masters using SQL:

psql -h ${PGENDPOINT} -p 5432 -U ${PGUSERNAME} ${DATABASE} \
-c "SELECT pg_last_xlog_receive_location() AS receive, pg_last_xlog_replay_location() AS replay , COALESCE(ROUND(EXTRACT(epoch FROM now() - pg_last_xact_replay_timestamp())),0) AS seconds;"

App changes

Now we have a multi-master replication. The application is still using the old master for read-write operations, but we need to change the application to a new master with a new PostgreSQL version.

After that you can stop your replication:

bucardo validate all
bucardo delta source_db
bucardo delta dest_db
bucardo deactivate mydb_sync
bucardo remove sync mydb_sync
bucardo stop

After stopping replica you can delete old RDS instance (we recommend you to create a snapshot before doing so), create read-only replica for new master and delete Bucardo EC2 instance.

Don’t forget to revoke privileges for superuser and remove Bucardo’s tables:

psql -h ${PGENDPOINT_2} -U ${PGUSERNAME} ${DATABASE} << EOF
DROP SCHEMA bucardo CASCADE;
REVOKE ALL PRIVILEGES ON ALL TABLES IN SCHEMA public FROM postgres;
REVOKE ALL PRIVILEGES ON ALL SEQUENCES IN SCHEMA public FROM postgres;
EOF

Cool. Now we are ready to try it on prod!

Production issues

We tested this multi-master replication on test servers and stage and it works really good. But let’s not forget that in production we have significantly more requests.

Bucardo uses streaming replication, it means that we need to use Bucardo host with PostgreSQL which controls all multi-master replications using WAL (Write-Ahead Log), so it’s not as fast as we wish.

When we have a lot of INSERT/UPDATE/DELETE operations with asynchronous streaming replication some lag may occur. If the app cannot control which master to use for write operations, we can get a primary keys collision. For example, when we are redeploying our app, some queries go to the old master and others to the new master.

Broken replication

So, in our case, we can’t use multi-master replication for production environment without changing app settings.

Upgrading production DB with downtime

First of all, you should set a maintenance window.

New Relic PostgreSQL metrics

It’s easy when you have the DB metrics. In our example, we have significantly fewer requests from 02:00 AM to 08:00 AM.

Also, it was a crucial understanding of which services cannot work during the DB downtime. We counted the downtime for RDS on test servers and it was only 4 min while it has reached 7 min on production server.

If you are all set and ready to rock and roll, here’s a production upgrade playbook for you to keep:

• make the first snapshot of production DB
• make the second snapshot of production DB (it’s significantly faster than previous)
• run VACUUM operation before stopping the instance
• modify DB version, instance type, parameters group and apply these changes immediately
• wait for upgrading DB
• delete old read-only replicas and create new ones

Key takeaways

RTFM: don’t use VACUUM FULL, instead of this use VACUUM command

VACUUM reclaims storage occupied by dead tuples without locking tables. VACUUM FULL rewrites all the table contents to a new disk file with no extra space, allowing unused space to be returned to the operating system. This form is much slower and requires an exclusive lock on each table while it is being processed. More information about it in PostgreSQL wiki.

Prepare your application for multi-master replication

If you want to use a multi-master replication in your project you need to make sure that the application will work with it correctly. Double check whether your application works with the DB and prepare the app for the multi-master.

Test everything

Run tests on all masters, check data consistency after tests, count possible downtime, etc.

Don’t forget about backups

Take snapshots as often as you can afford.

Communicate!

Gather all the information regarding the maintenance even if it doesn’t seem crucial. If you do maintenance during off business hours, make sure that there are at least a few people with different domain knowledge, who can assist.

Have a detailed maintenance plan

Have a clear playbook for every maintenance: literally the set of commands, which you have to execute.
