Prepare Deep-Learning-Ready VMs on Google Cloud Platform

Plus Some Practical Tips

Ceshine Lee
Aug 10, 2018 · 5 min read
Image for post
Image for post
Credit

The 2nd YouTube-8M Video Understanding Challenge has just finished. Google generously handed out $300 Google Cloud Platform(GCP) credits to the first 200 eligible people, and I was lucky enough to be one of them. I wouldn’t be able to participate in this challenge at a higher level otherwise. My local hardware can barely handle the size of the dataset and is not strong enough to handle the size of the model. The least I can do to return the favor is to write a short tutorial on how to set up deep-learning-ready VMs on GCP and about some tips that I’ve learned.

Cloud Compute and Its Pricing

By using ML Engine you can get rid of the problem of setting up the VM. It also comes with other tools like HyperTune. However, if your budget is tight, creating VMs on Cloud Compute will save you a lot of money. Especially after Cloud Compute started to offer “preemptiblity” option for GPUs earlier this year, and recently further dropped their prices. It’s so cheap that for me the costs incurred from storing the full 1.6 TB datasets were almost the same as from the K80 GPU core. (I used n1-standard-2/n1-standard-4 + 1 K80 core for training and n1-standard-4 for evaluating and predicting.)

The Prepackaged VM images

GCP actually provides images that work with GPUs now. I did not know that when I started working on this competition, so I started from scratch(to be precise, from one of my CPU VM snapshot). You can skip the next step which installs NVIDIA driver if you use these images.

Step 1: Install NVIDIA Driver

Find the corresponding driver on the NVIDIA website. For me, it’s Tesla Driver for Ubuntu 16.04 (Go to “SUPPORTED PRODUCTS” tab to double-check). Download and install it:

sudo dpkg -i nvidia-diag-driver-local-repo-ubuntu1604-384.145_1.0-1_amd64.debsudo apt-key add /var/nvidia-diag-driver-local-repo-384.145/7fa2af80.pubsudo apt-get updatesudo apt-get install cuda-drivers

Run nvidia-smi command to check if the installation was successful.

Step 2: Install nvidia-docker

Image for post
Image for post

I chose to use nvidia-docker and used docker images to mange my environments. As introduced in one of my previous post (link below), nvidia-docker only depends on the NVIDIA driver, so we get to use different versions of the CUDA toolkit in different images/containers. This can be extremely helpful when the pre-built binaries of deep learning frameworks supports different versions of CUDA toolkits.

Just follow the installation instruction from the nvidia-docker :

docker volume ls -q -f driver=nvidia-docker | xargs -r -I{} -n1 docker ps -q -a -f volume={} | xargs -r docker rm -fsudo apt-get purge -y nvidia-docker# Add the package repositoriescurl -s -L https://nvidia.github.io/nvidia-docker/gpgkey | \sudo apt-key add -distribution=$(. /etc/os-release;echo $ID$VERSION_ID) #ubuntu16.04curl -s -L https://nvidia.github.io/nvidia-docker/$distribution/nvidia-docker.list | \sudo tee /etc/apt/sources.list.d/nvidia-docker.listsudo apt-get update# Install nvidia-docker2 and reload the Docker daemon configurationsudo apt-get install -y nvidia-docker2sudo pkill -SIGHUP dockerd

Run docker run --runtime=nvidia --rm nvidia/cuda nvidia-smi to check if the installation was successful.

You’ll probably want to take a snapshot of the boot disk at this point.

Step 3: Pull or Build the Docker Image

For Tensorflow there are plenty of official images on Dokcer Hub, I used this image: tensorflow/tensorflow:1.8.0-gpu. Simply run this command to pull the image to local:

For PyTorch you have to build the image yourself locally. Clone the PyTorch Git repo and run this command:

Or you can write your own Dockerfile and includes all the packages you’d like to use in your project. Here are the ones I’ve been using: Tensorflow and PyTorch.

You are good to go! Start a container by docker run --runtime=nvidia -ti <other options> image_name bash and do training/prediction inside that container. The deep learning framework should be able to utilize the GPU core(s) now. It’s really this simple.

(Optional) Step 4: Create a Data Disk

Pro tip #1: It’s generally a good idea to separately store the dataset on a different disk from the boot/system disk. This also leads to independent snapshots of the dataset and system data. It adds a lot of flexibilities.

Image for post
Image for post

You’ll have to create the disk, and attach it to the VM either via Web UI or the command line tool. Then you’ll have to format the new disk and mount it:

sudo mkdir /datasudo mount -o discard,defaults /dev/sdb /data

To make the system auto-mount the new disk, edit this file: /etc/fstab.

Pro tip #2: You can share a data disk among different VMs as long as it’s attached in read-only mode. This is what you need to do:

  1. Create a VM and download the dataset to the data disk.
  2. Shutdown the VM, edit the VM options and change the attach mode of the data disk to read-only.
  3. Create another VM with the data disk attached in read-only mode.
Image for post
Image for post

Now you can run two VMs and two models simultaneously using the same data disk. Note that a disk have I/O limits, so don’t attach it to too many VMs:

Image for post
Image for post
An Example of Estimated Disk I/O Performance

(Optional) Step 5: Open Network Ports

If you plan to use Jupyter Notebook, Jupyter Lab, visdom, or Tensorboard on the VMs, you’ll need to open the corresponding ports in the firewall settings:

Image for post
Image for post

I recommend using a config file (e.g. jupyter_notebook_config.json) to set the password for Jupyter.

Thank You

This tutorial is not really GCP-specific except for the last two optional steps. It should be applicable to other cloud platforms and even to local machines with no or very little modification.

Having said that, I still had to spend quite some time searching and experimenting things I found on the Internet before finally reached a solution that I’m satisfied with. Hopefully this tutorial can save you folks some time. And please feel free to leave any kinds of feedback.
