Building a Share Button Interaction Concept using React Native and Software Mansion’s Reanimated — II

In this blog post, we continue our exploration of building the Share Button Interaction using Reanimated and Gesture Handler libraries.

If you haven’t read the previous blog post, make sure to check it out for an introduction to the project and the tools we’ll be using.

Cover Image by Fayas fs

The Ripple Effect ✨

The onTouchesUp and onFinalize functions are responsible for the ripple effect on tap.

The onTouchesUp the method is triggered when the user lifts their finger from the screen after making the tap gesture.

This function sets the rippleStateScale to a withTiming function to a value of 1 with a duration of 300ms and an easing function.

The onFinalize() is triggered when the tap gesture is complete. It sets the rippleStateOpacity which is an AnimatedSharedValue to a value of 0 and a duration of 500ms, then it resets the values of both rippleStateScale and rippleStateOpacity to initial values of 1 and 0, respectively.

This would result in a ripple effect where the View would scale up first and fades out.

The absolute positioned ripple effect View with the rippleEffect style from the useAnimatedStyle hook.

<Animated.View
style={[
tailwind.style(
'absolute -top-5 -right-5 bg-violet-600 rounded-full h-10 w-10 z-1 shadow-lg',
),
rippleEffect,
]}
/>

// Animating styles for the Ripple Effect View
const rippleEffect = useAnimatedStyle(() => {
return {
opacity: interpolate(rippleStateOpacity.value, [1, 0], [1, 0]),
transform: [{scale: interpolate(rippleStateScale.value, [0, 1], [1, 2])}],
};
});

The final interaction would look like this now with the Ripple Effect:

The Initial Menu Interaction with Ripple Effect

Well, this wraps up the whole Menu Interaction.

Share Icons Enter/Exit Animation

Let us add some icons to the Menu which would indicate it as a Share Menu.

I have picked Whatsapp, Twitter, and LinkedIn icons. Thanks to Deena Dhayalan for the icons.

I have separated the icons into a component <ShareIconStack />

type IconStackProps = {av: SharedValue<number>};

const ShareIconStack: React.FC<IconStackProps> = ({av}) => {
const appearStyle1 = useAnimatedStyle(() => {
return {
opacity: interpolate(av.value, [0, 0.95, 1], [1, 0, 0]),
transform: [{translateX: interpolate(av.value, [0, 1], [0, 100])}],
};
});
const appearStyle2 = useAnimatedStyle(() => {
return {
opacity: interpolate(av.value, [0, 0.95, 1], [1, 0, 0]),
transform: [{translateX: interpolate(av.value, [0, 1], [0, 70])}],
};
});
const appearStyle3 = useAnimatedStyle(() => {
return {
opacity: interpolate(av.value, [0, 0.95, 1], [1, 0, 0]),
transform: [{translateX: interpolate(av.value, [0, 1], [0, 36])}],
};
});
return (
<>
<Animated.View style={[tailwind.style('pr-2'), appearStyle1]}>
<Svg width="24" height="24" fill="none" viewBox="0 0 24 24">
<Path
fillRule="evenodd"
d="M1 2.838A1.838 1.838 0 0 1 2.838 1H21.16A1.837 1.837 0 0 1 23 2.838V21.16A1.838 1.838 0 0 1 21.161 23H2.838A1.838 1.838 0 0 1 1 21.161V2.838zm8.708 6.55h2.979v1.496c.43-.86 1.53-1.634 3.183-1.634 3.169 0 3.92 1.713 3.92 4.856v5.822h-3.207v-5.106c0-1.79-.43-2.8-1.522-2.8-1.515 0-2.145 1.089-2.145 2.8v5.106H9.708V9.388zm-5.5 10.403h3.208V9.25H4.208v10.54zM7.875 5.812a2.063 2.063 0 1 1-4.125 0 2.063 2.063 0 0 1 4.125 0z"
clipRule="evenodd"
fill={tailwind.color('text-white')}
/>
</Svg>
</Animated.View>
<Animated.View style={[tailwind.style('pr-2'), appearStyle2]}>
<Svg width="24" height="24" fill="none" viewBox="0 0 24 24">
<Path
fill={tailwind.color('text-white')}
d="M23.643 4.937c-.835.37-1.732.62-2.675.733a4.67 4.67 0 0 0 2.048-2.578 9.3 9.3 0 0 1-2.958 1.13 4.66 4.66 0 0 0-7.938 4.25 13.229 13.229 0 0 1-9.602-4.868c-.4.69-.63 1.49-.63 2.342A4.66 4.66 0 0 0 3.96 9.824a4.647 4.647 0 0 1-2.11-.583v.06a4.66 4.66 0 0 0 3.737 4.568 4.692 4.692 0 0 1-2.104.08 4.661 4.661 0 0 0 4.352 3.234 9.348 9.348 0 0 1-5.786 1.995 9.5 9.5 0 0 1-1.112-.065 13.175 13.175 0 0 0 7.14 2.093c8.57 0 13.255-7.098 13.255-13.254 0-.2-.005-.402-.014-.602a9.47 9.47 0 0 0 2.323-2.41l.002-.003z"
/>
</Svg>
</Animated.View>
<Animated.View style={[tailwind.style('pr-1'), appearStyle3]}>
<Svg width="24" height="24" viewBox="0 0 24 24" fill="none">
<Path
d="M21.9803 11.4104C21.6403 5.61044 16.3703 1.14045 10.3003 2.14045C6.12029 2.83045 2.77029 6.22043 2.12029 10.4004C1.74029 12.8204 2.24031 15.1104 3.33031 17.0004L2.4403 20.3104C2.2403 21.0604 2.93028 21.7404 3.67028 21.5304L6.93029 20.6304C8.41029 21.5004 10.1403 22.0004 11.9903 22.0004C17.6303 22.0004 22.3103 17.0304 21.9803 11.4104ZM16.8803 15.7204C16.7903 15.9004 16.6803 16.0704 16.5403 16.2304C16.2903 16.5004 16.0203 16.7004 15.7203 16.8204C15.4203 16.9504 15.0903 17.0104 14.7403 17.0104C14.2303 17.0104 13.6803 16.8905 13.1103 16.6405C12.5303 16.3905 11.9603 16.0604 11.3903 15.6504C10.8103 15.2304 10.2703 14.7604 9.7503 14.2504C9.2303 13.7304 8.77027 13.1804 8.35027 12.6104C7.94027 12.0404 7.61029 11.4704 7.37029 10.9004C7.13029 10.3304 7.01031 9.78045 7.01031 9.26045C7.01031 8.92044 7.0703 8.59044 7.1903 8.29044C7.3103 7.98044 7.50032 7.70045 7.77032 7.45045C8.09032 7.13045 8.4403 6.98045 8.8103 6.98045C8.95029 6.98045 9.09027 7.01044 9.22027 7.07044C9.35027 7.13044 9.47029 7.22044 9.5603 7.35044L10.7203 8.99043C10.8103 9.12043 10.8803 9.23043 10.9203 9.34043C10.9703 9.45043 10.9903 9.55043 10.9903 9.65043C10.9903 9.77043 10.9503 9.89045 10.8803 10.0104C10.8103 10.1304 10.7203 10.2504 10.6003 10.3704L10.2203 10.7704C10.1603 10.8304 10.1403 10.8904 10.1403 10.9704C10.1403 11.0104 10.1503 11.0504 10.1603 11.0904C10.1803 11.1304 10.1903 11.1604 10.2003 11.1904C10.2903 11.3604 10.4503 11.5704 10.6703 11.8304C10.9003 12.0904 11.1403 12.3604 11.4003 12.6204C11.6703 12.8904 11.9303 13.1304 12.2003 13.3604C12.4603 13.5804 12.6803 13.7304 12.8503 13.8204C12.8803 13.8304 12.9103 13.8504 12.9403 13.8604C12.9803 13.8804 13.0203 13.8804 13.0703 13.8804C13.1603 13.8804 13.2203 13.8504 13.2803 13.7904L13.6603 13.4104C13.7903 13.2804 13.9103 13.1904 14.0203 13.1304C14.1403 13.0604 14.2503 13.0204 14.3803 13.0204C14.4803 13.0204 14.5803 13.0404 14.6903 13.0904C14.8003 13.1404 14.9203 13.2004 15.0403 13.2904L16.7003 14.4704C16.8303 14.5604 16.9203 14.6704 16.9803 14.7904C17.0303 14.9204 17.0603 15.0404 17.0603 15.1804C17.0003 15.3504 16.9603 15.5404 16.8803 15.7204Z"
fill={tailwind.color('text-white')}
/>
</Svg>
</Animated.View>
</>
);
};

The component accepts one prop called av which is an animating variable, i.e. our iconState from the parent component.

This state can be used to set the enter/exit animations for the icons.

Like to slide from right to left and vice versa.

So we have three appearStyle animations for our Icons, which manipulates the same style attributes: the opacity and translateX from the transform.

I think you will now know what opacity interpolate does.
Let me try to explain just the transform property.

The translateX property is animated using the interpolate method, which maps the changing value av.value from input range [0, 1] to the output range of [0, 36] , [0, 70] and [0, 100] for the three icons.

This causes the icon to translate horizontally from 0 to 36, 70, and 100 units as av.value changes from 0 to 1. Giving us the entering animation.

Let us see how our whole interaction looks now with everything stitched together.

Final Share Menu Animation

The Final Code

import React from 'react';
import {Pressable} from 'react-native';
import {Gesture, GestureDetector} from 'react-native-gesture-handler';
import LinearGradient from 'react-native-linear-gradient';
import Animated, {
Easing,
interpolate,
SharedValue,
useAnimatedStyle,
useSharedValue,
withSpring,
WithSpringConfig,
withTiming,
} from 'react-native-reanimated';
import Svg, {Path} from 'react-native-svg';
import tailwind from 'twrnc';

const AnimatedLinearGradient = Animated.createAnimatedComponent(LinearGradient);

const SHARE_SPRING_CONFIG: WithSpringConfig = {
mass: 1,
damping: 20,
stiffness: 300,
overshootClamping: false,
restSpeedThreshold: 0.01,
restDisplacementThreshold: 0.01,
};

const CLOSE_SPRING_CONFIG: WithSpringConfig = {
mass: 1,
damping: 20,
stiffness: 150,
overshootClamping: false,
restSpeedThreshold: 0.01,
restDisplacementThreshold: 0.01,
};

type IconStackProps = {av: SharedValue<number>};

const ShareIconStack: React.FC<IconStackProps> = ({av}) => {
const appearStyle1 = useAnimatedStyle(() => {
return {
opacity: interpolate(av.value, [0, 0.95, 1], [1, 0, 0]),
transform: [{translateX: interpolate(av.value, [0, 1], [0, 100])}],
};
});
const appearStyle2 = useAnimatedStyle(() => {
return {
opacity: interpolate(av.value, [0, 0.95, 1], [1, 0, 0]),
transform: [{translateX: interpolate(av.value, [0, 1], [0, 70])}],
};
});
const appearStyle3 = useAnimatedStyle(() => {
return {
opacity: interpolate(av.value, [0, 0.95, 1], [1, 0, 0]),
transform: [{translateX: interpolate(av.value, [0, 1], [0, 36])}],
};
});
return (
<>
<Animated.View style={[tailwind.style('pr-2'), appearStyle1]}>
<Svg width="24" height="24" fill="none" viewBox="0 0 24 24">
<Path
fillRule="evenodd"
d="M1 2.838A1.838 1.838 0 0 1 2.838 1H21.16A1.837 1.837 0 0 1 23 2.838V21.16A1.838 1.838 0 0 1 21.161 23H2.838A1.838 1.838 0 0 1 1 21.161V2.838zm8.708 6.55h2.979v1.496c.43-.86 1.53-1.634 3.183-1.634 3.169 0 3.92 1.713 3.92 4.856v5.822h-3.207v-5.106c0-1.79-.43-2.8-1.522-2.8-1.515 0-2.145 1.089-2.145 2.8v5.106H9.708V9.388zm-5.5 10.403h3.208V9.25H4.208v10.54zM7.875 5.812a2.063 2.063 0 1 1-4.125 0 2.063 2.063 0 0 1 4.125 0z"
clipRule="evenodd"
fill={tailwind.color('text-white')}
/>
</Svg>
</Animated.View>
<Animated.View style={[tailwind.style('pr-2'), appearStyle2]}>
<Svg width="24" height="24" fill="none" viewBox="0 0 24 24">
<Path
fill={tailwind.color('text-white')}
d="M23.643 4.937c-.835.37-1.732.62-2.675.733a4.67 4.67 0 0 0 2.048-2.578 9.3 9.3 0 0 1-2.958 1.13 4.66 4.66 0 0 0-7.938 4.25 13.229 13.229 0 0 1-9.602-4.868c-.4.69-.63 1.49-.63 2.342A4.66 4.66 0 0 0 3.96 9.824a4.647 4.647 0 0 1-2.11-.583v.06a4.66 4.66 0 0 0 3.737 4.568 4.692 4.692 0 0 1-2.104.08 4.661 4.661 0 0 0 4.352 3.234 9.348 9.348 0 0 1-5.786 1.995 9.5 9.5 0 0 1-1.112-.065 13.175 13.175 0 0 0 7.14 2.093c8.57 0 13.255-7.098 13.255-13.254 0-.2-.005-.402-.014-.602a9.47 9.47 0 0 0 2.323-2.41l.002-.003z"
/>
</Svg>
</Animated.View>
<Animated.View style={[tailwind.style('pr-1'), appearStyle3]}>
<Svg width="24" height="24" viewBox="0 0 24 24" fill="none">
<Path
d="M21.9803 11.4104C21.6403 5.61044 16.3703 1.14045 10.3003 2.14045C6.12029 2.83045 2.77029 6.22043 2.12029 10.4004C1.74029 12.8204 2.24031 15.1104 3.33031 17.0004L2.4403 20.3104C2.2403 21.0604 2.93028 21.7404 3.67028 21.5304L6.93029 20.6304C8.41029 21.5004 10.1403 22.0004 11.9903 22.0004C17.6303 22.0004 22.3103 17.0304 21.9803 11.4104ZM16.8803 15.7204C16.7903 15.9004 16.6803 16.0704 16.5403 16.2304C16.2903 16.5004 16.0203 16.7004 15.7203 16.8204C15.4203 16.9504 15.0903 17.0104 14.7403 17.0104C14.2303 17.0104 13.6803 16.8905 13.1103 16.6405C12.5303 16.3905 11.9603 16.0604 11.3903 15.6504C10.8103 15.2304 10.2703 14.7604 9.7503 14.2504C9.2303 13.7304 8.77027 13.1804 8.35027 12.6104C7.94027 12.0404 7.61029 11.4704 7.37029 10.9004C7.13029 10.3304 7.01031 9.78045 7.01031 9.26045C7.01031 8.92044 7.0703 8.59044 7.1903 8.29044C7.3103 7.98044 7.50032 7.70045 7.77032 7.45045C8.09032 7.13045 8.4403 6.98045 8.8103 6.98045C8.95029 6.98045 9.09027 7.01044 9.22027 7.07044C9.35027 7.13044 9.47029 7.22044 9.5603 7.35044L10.7203 8.99043C10.8103 9.12043 10.8803 9.23043 10.9203 9.34043C10.9703 9.45043 10.9903 9.55043 10.9903 9.65043C10.9903 9.77043 10.9503 9.89045 10.8803 10.0104C10.8103 10.1304 10.7203 10.2504 10.6003 10.3704L10.2203 10.7704C10.1603 10.8304 10.1403 10.8904 10.1403 10.9704C10.1403 11.0104 10.1503 11.0504 10.1603 11.0904C10.1803 11.1304 10.1903 11.1604 10.2003 11.1904C10.2903 11.3604 10.4503 11.5704 10.6703 11.8304C10.9003 12.0904 11.1403 12.3604 11.4003 12.6204C11.6703 12.8904 11.9303 13.1304 12.2003 13.3604C12.4603 13.5804 12.6803 13.7304 12.8503 13.8204C12.8803 13.8304 12.9103 13.8504 12.9403 13.8604C12.9803 13.8804 13.0203 13.8804 13.0703 13.8804C13.1603 13.8804 13.2203 13.8504 13.2803 13.7904L13.6603 13.4104C13.7903 13.2804 13.9103 13.1904 14.0203 13.1304C14.1403 13.0604 14.2503 13.0204 14.3803 13.0204C14.4803 13.0204 14.5803 13.0404 14.6903 13.0904C14.8003 13.1404 14.9203 13.2004 15.0403 13.2904L16.7003 14.4704C16.8303 14.5604 16.9203 14.6704 16.9803 14.7904C17.0303 14.9204 17.0603 15.0404 17.0603 15.1804C17.0003 15.3504 16.9603 15.5404 16.8803 15.7204Z"
fill={tailwind.color('text-white')}
/>
</Svg>
</Animated.View>
</>
);
};

const CloseIcon = () => {
return (
<Svg width="28" height="28" fill="none" viewBox="0 0 24 24">
<Path
stroke="white"
strokeLinecap="round"
strokeLinejoin="round"
strokeWidth="2"
d="M17.25 6.75L6.75 17.25"
/>
<Path
stroke="white"
strokeLinecap="round"
strokeLinejoin="round"
strokeWidth="2"
d="M6.75 6.75L17.25 17.25"
/>
</Svg>
);
};
const ShareIcon = () => {
return (
<Svg width="24" height="24" fill="none" viewBox="0 0 24 24">
<Path
stroke="white"
strokeLinecap="round"
strokeLinejoin="round"
strokeWidth="2"
d="M9.25 4.75H6.75C5.64543 4.75 4.75 5.64543 4.75 6.75V17.25C4.75 18.3546 5.64543 19.25 6.75 19.25H17.25C18.3546 19.25 19.25 18.3546 19.25 17.25V14.75"
/>
<Path
stroke="white"
strokeLinecap="round"
strokeLinejoin="round"
strokeWidth="2"
d="M19.25 9.25V4.75H14.75"
/>
<Path
stroke="white"
strokeLinecap="round"
strokeLinejoin="round"
strokeWidth="2"
d="M19 5L11.75 12.25"
/>
</Svg>
);
};

export const ShareAnimationConceptScreen = () => {
const iconState = useSharedValue(1);
const rippleStateScale = useSharedValue(0);
const rippleStateOpacity = useSharedValue(1);

const shareIconStyle = useAnimatedStyle(() => {
return {
opacity: interpolate(iconState.value, [0, 1], [0, 1]),
zIndex: interpolate(iconState.value, [0, 1], [0, 9999]),

transform: [{scale: interpolate(iconState.value, [0, 1], [0.7, 1])}],
};
});
const closeIconStyle = useAnimatedStyle(() => {
return {
opacity: interpolate(iconState.value, [1, 0], [0, 1]),
zIndex: interpolate(iconState.value, [1, 0], [0, 9999]),
transform: [{scale: interpolate(iconState.value, [1, 0], [0.7, 1])}],
};
});
const containerStyle = useAnimatedStyle(() => {
return {
width: interpolate(iconState.value, [1, 0], [40, 144]),
};
});

const rippleEffect = useAnimatedStyle(() => {
return {
opacity: interpolate(rippleStateOpacity.value, [1, 0], [1, 0]),
transform: [{scale: interpolate(rippleStateScale.value, [0, 1], [1, 2])}],
};
});

const shareTapHandler = Gesture.Tap()
.maxDistance(1)
.onStart(() => {
'worklet';
iconState.value = withSpring(0, SHARE_SPRING_CONFIG);
})
.onTouchesUp(() => {
rippleStateScale.value = withTiming(1, {
duration: 300,
easing: Easing.out(Easing.ease),
});
})
.onFinalize(() => {
rippleStateOpacity.value = withTiming(
0,
{duration: 500, easing: Easing.out(Easing.ease)},
() => {
rippleStateOpacity.value = 1;
rippleStateScale.value = 0;
},
);
});

const closeTapHandler = Gesture.Tap()
.maxDistance(1)
.onStart(() => {
'worklet';
iconState.value = withSpring(1, CLOSE_SPRING_CONFIG);
})
.onTouchesUp(() => {
rippleStateScale.value = withTiming(1, {
duration: 300,
easing: Easing.out(Easing.ease),
});
})
.onFinalize(() => {
rippleStateOpacity.value = withTiming(
0,
{duration: 500, easing: Easing.out(Easing.ease)},
() => {
rippleStateOpacity.value = 1;
rippleStateScale.value = 0;
},
);
});
return (
<Pressable style={tailwind.style('w-full px-5')}>
<Animated.View style={tailwind.style('relative z-10')}>
<Animated.View
style={[
tailwind.style(
'absolute -top-5 -right-5 bg-violet-600 rounded-full h-10 w-10 z-1 shadow-lg',
),
rippleEffect,
]}
/>
<Animated.View
style={[
tailwind.style(
'absolute -top-5 -right-5 bg-violet-900 flex-row items-center justify-end rounded-full h-10 z-10 shadow-lg',
),
containerStyle,
]}>
<GestureDetector gesture={shareTapHandler}>
<Animated.View
style={[tailwind.style('absolute right-2'), shareIconStyle]}>
<ShareIcon />
</Animated.View>
</GestureDetector>
<ShareIconStack av={iconState} />
<GestureDetector gesture={closeTapHandler}>
<Animated.View style={[tailwind.style('pr-2'), closeIconStyle]}>
<CloseIcon />
</Animated.View>
</GestureDetector>
</Animated.View>
</Animated.View>
<AnimatedLinearGradient
style={tailwind.style('p-5 rounded-lg')}
start={{x: 0.0, y: 0.25}}
end={{x: 0.5, y: 1.0}}
angle={65}
useAngle={true}
colors={[
tailwind.color('text-violet-700') as string,
tailwind.color('text-violet-500') as string,
tailwind.color('text-violet-600') as string,
tailwind.color('text-violet-500') as string,
tailwind.color('text-violet-700') as string,
]}>
<Animated.Text style={tailwind.style('text-white')}>
Earnings today
</Animated.Text>
<Animated.Text style={tailwind.style('text-white text-5xl pt-6')}>
₹10,421.56
</Animated.Text>
<Animated.View
style={tailwind.style('flex flex-row items-center pt-2')}>
<Animated.View
style={tailwind.style('px-1 py-0.5 bg-violet-800 rounded-md')}>
<Animated.Text
style={tailwind.style('text-white text-sm tracking-wider')}>
+1.5%
</Animated.Text>
</Animated.View>
<Animated.Text
style={tailwind.style('text-white text-sm tracking-wide pl-1')}>
Higher earnings than usual
</Animated.Text>
</Animated.View>
</AnimatedLinearGradient>
</Pressable>
);
};

This wraps our two-part blog series on Building a Share Button Interaction Concept using React Native and Software Mansions’ Reanimated.

Thank you for following along! I hope you have enjoyed it and I look forward to sharing more UI Interactions in the future.

This is Karthik from Timeless.

If you found this series helpful, please consider sharing it on social media.

UI Interactions With React Native and Reanimated

4 stories
Cover photo for the blog reading the title which is Building the Animated Sticky-Spotify Collapsible Header with React Native and Reanimated — Part II

Follow our publication and stay tuned.

I hope you found this blog post helpful and informative. If you have any feedback or suggestions, please leave a comment below. I’d love to hear your thoughts and opinions on the topic.

Happy coding!

--

--

Get the Medium app

A button that says 'Download on the App Store', and if clicked it will lead you to the iOS App store
A button that says 'Get it on, Google Play', and if clicked it will lead you to the Google Play store
Karthik Balasubramanian

Trying to Solve Problems with Code @ timeless.co. Open sourcing the solutions when possible.
