5 Easy Steps to Understanding JSON Web Tokens (JWT)

In this article, the fundamentals of what JSON Web Tokens (JWT) are, and why they are used will be explained. JWT are an important piece in ensuring trust and security in your application. JWT allow claims, such as user data, to be represented in a secure manner.

To explain how JWT work, let’s begin with an abstract definition.

A JSON Web Token (JWT) is a JSON object that is defined in RFC 7519 as a safe way to represent a set of information between two parties. The token is composed of a header, a payload, and a signature.

Simply put, a JWT is just a string with the following format:

header.payload.signature

It should be noted that a double quoted string is actually considered a valid JSON object.

To show how and why JWT are actually used, we will use a simple 3 entity example (see the below diagram). The entities in this example are the user, the application server, and the authentication server. The authentication server will provide the JWT to the user. With the JWT, the user can then safely communicate with the application.

How an application uses JWT to verify the authenticity of a user.

In this example, the user first signs into the authentication server using the authentication server’s login system (e.g. username and password, Facebook login, Google login, etc). The authentication server then creates the JWT and sends it to the user. When the user makes API calls to the application, the user passes the JWT along with the API call. In this setup, the application server would be configured to verify that the incoming JWT are created by the authentication server (the verification process will be explained in more detail later). So, when the user makes API calls with the attached JWT, the application can use the JWT to verify that the API call is coming from an authenticated user.

Now, the JWT itself, and how it’s constructed and verified, will be examined in more depth.

Step 1. Create the HEADER

The header component of the JWT contains information about how the JWT signature should be computed. The header is a JSON object in the following format:

In this JSON, the value of the “typ” key specifies that the object is a JWT, and the value of the “alg” key specifies which hashing algorithm is being used to create the JWT signature component. In our example, we’re using the HMAC-SHA256 algorithm, a hashing algorithm that uses a secret key, to compute the signature (discussed in more detail in step 3).

Step 2. Create the PAYLOAD

The payload component of the JWT is the data that‘s stored inside the JWT (this data is also referred to as the “claims” of the JWT). In our example, the authentication server creates a JWT with the user information stored inside of it, specifically the user ID.

The data inside the payload is referred to as the “claims” of the token.

In our example, we are only putting one claim into the payload. You can put as many claims as you like. There are several different standard claims for the JWT payload, such as “iss” the issuer, “sub” the subject, and “exp” the expiration time. These fields can be useful when creating JWT, but they are optional. See the wikipedia page on JWT for a more detailed list of JWT standard fields.

Keep in mind that the size of the data will affect the overall size of the JWT, this generally isn’t an issue but having excessively large JWT may negatively affect performance and cause latency.

Step 3. Create the SIGNATURE

The signature is computed using the following pseudo code:

// signature algorithm
data = base64urlEncode( header ) + “.” + base64urlEncode( payload )
signature = Hash( data, secret );

What this algorithm does is base64url encodes the header and the payload created in steps 1 and 2. The algorithm then joins the resulting encoded strings together with a period (.) in between them. In our pseudo code, this joined string is assigned to data. To get the JWT signature, the data string is hashed with the secret key using the hashing algorithm specified in the JWT header.

In our example, both the header, and the payload are base64url encoded as:

// header
eyJ0eXAiOiJKV1QiLCJhbGciOiJIUzI1NiJ9
// payload
eyJ1c2VySWQiOiJiMDhmODZhZi0zNWRhLTQ4ZjItOGZhYi1jZWYzOTA0NjYwYmQifQ

Then, using the joined encoded header and payload, and applying the specified signature algorithm(HS256) on the data string with the secret key set as the string “secret”, we get the following JWT Signature:

// signature
-xN_h82PHVTCMA9vdoHrcZxH-x5mb11y1537t3rGzcM

Step 4. Put All Three JWT Components Together

Now that we have created all three components, we can create the JWT. Remembering the header.payload.signature structure of the JWT, we simply need to combine the components, with periods (.) separating them. We use the base64url encoded versions of the header and of the payload, and the signature we arrived at in step 3.

// JWT Token
eyJ0eXAiOiJKV1QiLCJhbGciOiJIUzI1NiJ9.eyJ1c2VySWQiOiJiMDhmODZhZi0zNWRhLTQ4ZjItOGZhYi1jZWYzOTA0NjYwYmQifQ.-xN_h82PHVTCMA9vdoHrcZxH-x5mb11y1537t3rGzcM

You can try creating your own JWT through your browser at jwt.io.

Going back to our example, the authentication server can now send this JWT to the user.

How does JWT protect our data?

It is important to understand that the purpose of using JWT is NOT to hide or obscure data in any way. The reason why JWT are used is to prove that the sent data was actually created by an authentic source.

As demonstrated in the previous steps, the data inside a JWT is encoded and signed, not encrypted. The purpose of encoding data is to transform the data’s structure. Signing data allows the data receiver to verify the authenticity of the source of the data. So encoding and signing data does NOT secure the data. On the other hand, the main purpose of encryption is to secure the data and to prevent unauthorized access. For a more detailed explanation of the differences between encoding and encryption, and also for more information on how hashing works, see this article.

Since JWT are signed and encoded only, and since JWT are not encrypted, JWT do not guarantee any security for sensitive data.

Step 5. Verifying the JWT

In our simple 3 entity example, we are using a JWT that is signed by the HS256 algorithm where only the authentication server and the application server know the secret key. The application server receives the secret key from the authentication server when the application sets up its authentication process. Since the application knows the secret key, when the user makes a JWT-attached API call to the application, the application can perform the same signature algorithm as in Step 3 on the JWT. The application can then verify that the signature obtained from it’s own hashing operation matches the signature on the JWT itself (i.e. it matches the JWT signature created by the authentication server). If the signatures match, then that means the JWT is valid which indicates that the API call is coming from an authentic source. Otherwise, if the signatures don’t match, then it means that the received JWT is invalid, which may be an indicator of a potential attack on the application. So by verifying the JWT, the application adds a layer of trust between itself and the user.

In Conclusion

We went over what JWT are, how they are created and validated, and how they can be used to ensure trust between an application and its users. This is a starting point for understanding the fundamentals of JWT and why they are useful. JWT are just one piece of the puzzle in ensuring trust and security in your application.
